Panasonic Lumix DMC-GH4 User Manual

103
4. Focus and Shutter (Drive Mode) Settings
You can set the focus position precisely by enlarging the screen.
•
The focus position cannot be set at the edge of the screen.
1 Press [].
2 Select [ ] and press 4.
3 Press 3/4/2/1 to set the focus position and then
press [MENU/SET].
•
The assist screen for setting the focus position is displayed
in an enlarged size.
• The assist screen can also be displayed by touching the
subject.
4 Move [+] to the position to be in focus.
•
When the picture is displayed in windowed mode, you can enlarge/reduce the picture by
approximately 3 to 6
k; when the picture is displayed in full screen, you can enlarge/
reduce the picture by approximately 3 to 10
k.
• If you use the HDMI output during recording, the screen cannot be enlarged in windowed
mode.
• On the assist screen, it is also possible to record a picture by touching [ ].
When selecting [ ]
Button
operation
Touch
operation
Description of operation
3/4/2/1 Touching Moves [+].
Pinching in/
out
Enlarges/reduces the screen (by steps of 0.1
k)
s Enlarges/reduces the screen (by steps of 1.0k)
Switches the enlarged display (windowed/full screen)
[DISP.] [Reset] Resets [+] back to the center.

Panasonic Lumix DMC-GH4 Specifications

General

Sensor Type	Live MOS
Effective Pixels	16.05 Megapixels
Dimensions	132.9 x 93.4 x 83.9 mm
Lens Mount	Micro Four Thirds
Built-in Flash	No
External Flash	Hot shoe
Sensor Size	17.3 x 13.0 mm
ISO Sensitivity	ISO 200-25600
Autofocus System	Contrast Detect AF
Shutter Speed	1/8000 to 60 sec
Continuous Shooting Speed	12 fps
Video Recording	4K (4096 x 2160) at 24 fps, Full HD (1920 x 1080) at 60/30/24 fps
Viewfinder	Electronic (OLED) with 2, 359k dots
Screen	3.0-inch Fully Articulated Touchscreen, 1, 036, 000 dots
Battery Life	Approx. 500 shots (CIPA standard)
Weight	560 g
File Formats	JPEG, RAW, MP4
Connectivity	Wi-Fi, NFC, HDMI, USB 2.0
Storage Media	SD/SDHC/SDXC card
