Panasonic Lumix DMC-GH4 User Manual

6. Recording Suited for the Subject and Scene
152
Determine the exposure by manually setting the aperture value and the shutter speed.
The Manual Exposure Assistance appears on the lower portion of the screen to indicate
the exposure.
1
Set the mode dial to [ ].
2
Rotate the rear dial to set the shutter speed,
and rotate the front dial to set the aperture
value.
A Exposure meter
B Aperture value
C Shutter speed
D Manual Exposure Assistance
Optimizing the ISO sensitivity for the shutter speed and aperture value
When the ISO sensitivity is set to [AUTO], the camera sets the ISO sensitivity
automatically so that the exposure will be appropriate for the shutter speed and aperture
value.
•
Depending on recording conditions, an appropriate exposure may not be set or the ISO
sensitivity may become higher.
Manual Exposure Mode
Aperture value
Reduces
It becomes easier to defocus the
background.
Increases
It becomes easier to maintain
focus as far as the background.
Shutter speed
Slow
It becomes easier to express
movement.
Fast
It becomes easier to freeze
movement.
SSSSSS
F
1258
5.64.02.8 8.0 11
603015
3030305.6
00 +3
DB
A
C

Panasonic Lumix DMC-GH4 Specifications

General

Sensor Type	Live MOS
Effective Pixels	16.05 Megapixels
Dimensions	132.9 x 93.4 x 83.9 mm
Lens Mount	Micro Four Thirds
Built-in Flash	No
External Flash	Hot shoe
Sensor Size	17.3 x 13.0 mm
ISO Sensitivity	ISO 200-25600
Autofocus System	Contrast Detect AF
Shutter Speed	1/8000 to 60 sec
Continuous Shooting Speed	12 fps
Video Recording	4K (4096 x 2160) at 24 fps, Full HD (1920 x 1080) at 60/30/24 fps
Viewfinder	Electronic (OLED) with 2, 359k dots
Screen	3.0-inch Fully Articulated Touchscreen, 1, 036, 000 dots
Battery Life	Approx. 500 shots (CIPA standard)
Weight	560 g
File Formats	JPEG, RAW, MP4
Connectivity	Wi-Fi, NFC, HDMI, USB 2.0
Storage Media	SD/SDHC/SDXC card
