Panasonic Lumix DMC-GH4 User Manual

4. Focus and Shutter (Drive Mode) Settings
104
By setting [Touch Pad AF] in [Touch Settings] (P314) in the
[Custom] menu, you can move the AF area displayed on the
viewfinder by touching the monitor.
•
If you touch the monitor when the Auto Focus Mode is set to
[Custom Multi] such as [ ], the AF area setting screen will be
displayed. (P99)
• Press the shutter button halfway to determine the focus position.
If you press [DISP.] before determining the focus position, the AF area frame returns to the
center position.
• To cancel the AF area frame when the Auto Focus Mode (P91) is set to [š] ([Face/Eye
Detection]), [ ] ([Tracking]) or [ ] ([49-Area]), press [MENU/SET].
• The Touch Shutter function (P89) is disabled when using [Touch Pad AF].
Setting the AF area position with the Touch Pad
Applicable modes:
> [Custom] > [Touch Settings] > [Touch Pad AF]
[EXACT]
Moves the AF area of the
Viewfinder by touching a
desired position on the Touch
Pad.
[OFFSET]
Moves the AF area of the
viewfinder according to the
distance you drag the touch
pad (P49).
[OFF] —
MENU

Panasonic Lumix DMC-GH4 Specifications

General

Sensor Type	Live MOS
Effective Pixels	16.05 Megapixels
Dimensions	132.9 x 93.4 x 83.9 mm
Lens Mount	Micro Four Thirds
Built-in Flash	No
External Flash	Hot shoe
Sensor Size	17.3 x 13.0 mm
ISO Sensitivity	ISO 200-25600
Autofocus System	Contrast Detect AF
Shutter Speed	1/8000 to 60 sec
Continuous Shooting Speed	12 fps
Video Recording	4K (4096 x 2160) at 24 fps, Full HD (1920 x 1080) at 60/30/24 fps
Viewfinder	Electronic (OLED) with 2, 359k dots
Screen	3.0-inch Fully Articulated Touchscreen, 1, 036, 000 dots
Battery Life	Approx. 500 shots (CIPA standard)
Weight	560 g
File Formats	JPEG, RAW, MP4
Connectivity	Wi-Fi, NFC, HDMI, USB 2.0
Storage Media	SD/SDHC/SDXC card
