Panasonic Lumix DMC-GH4 User Manual

151
6. Recording Suited for the Subject and Scene
When you set the shutter speed, the camera automatically optimizes the aperture value
for the brightness of the subject.
When you want to take a sharp picture of a fast moving subject, set with a faster shutter
speed. When you want to create a trail effect, set to a slower shutter speed.
1
Set the mode dial to [ ].
2
Set the shutter speed by rotating the rear dial
or the front dial.
A Shutter speed
B Exposure meter
• Rotate the front/rear dial to display the Exposure Meter. Unsuitable areas of the range are
displayed in red.
• If the exposure is not adequate, the aperture value and the shutter speed turn red and blink
when the shutter button is pressed halfway.
• We recommend using a tripod when the shutter speed is slow.
• When the ISO sensitivity is set to [ ], it will switch to [AUTO].
Not available in these cases:
•
When the flash is activated, the fastest shutter speed that can be selected is 1/250th of a
second. (P184)
• The shutter speed slower than 1 second is not available when [Electronic Shutter] is set to
[ON].
Shutter-Priority AE Mode
Shutter speed:
Slow
Shutter speed:
Fast
It becomes easier to
express movement.
It becomes easier to
freeze movement.
SSSSSS
F
250250250
60
5.6 4.0 2.8
250 500125
1 000
A
B

Panasonic Lumix DMC-GH4 Specifications

General

Sensor Type	Live MOS
Effective Pixels	16.05 Megapixels
Dimensions	132.9 x 93.4 x 83.9 mm
Lens Mount	Micro Four Thirds
Built-in Flash	No
External Flash	Hot shoe
Sensor Size	17.3 x 13.0 mm
ISO Sensitivity	ISO 200-25600
Autofocus System	Contrast Detect AF
Shutter Speed	1/8000 to 60 sec
Continuous Shooting Speed	12 fps
Video Recording	4K (4096 x 2160) at 24 fps, Full HD (1920 x 1080) at 60/30/24 fps
Viewfinder	Electronic (OLED) with 2, 359k dots
Screen	3.0-inch Fully Articulated Touchscreen, 1, 036, 000 dots
Battery Life	Approx. 500 shots (CIPA standard)
Weight	560 g
File Formats	JPEG, RAW, MP4
Connectivity	Wi-Fi, NFC, HDMI, USB 2.0
Storage Media	SD/SDHC/SDXC card
