Panasonic Lumix DMC-GH4 User Manual

4. Focus and Shutter (Drive Mode) Settings
122
9 Select the methods for creating a motion picture.
•
The recording format is set to [MP4].
10 Select [OK] with 3/4, and then press [MENU/SET].
•
Confirmation screen is displayed. It is executed when [Yes]
is selected.
• Motion pictures can also be created from [Time Lapse
Video] in the [Playback] menu. (P243)
[Rec Quality]
Sets the quality of a motion picture.
• When [System Frequency] is set to [59.94 Hz (NTSC)]
[4K/30p]/[FHD/60p]/[FHD/30p]/[HD/30p]/[VGA/30p]
•
When [System Frequency] is set to [50.00 Hz (PAL)]
[4K/25p]/[FHD/50p]/[FHD/25p]/[HD/25p]/[VGA/25p]
[Frame Rate]
Sets the number of frames per second.
The larger the number is, the smoother the motion picture will be.
• When [System Frequency] is set to [59.94 Hz (NTSC)]
[60fps]
¢
/[30fps]/[15fps]/[10fps]/[7.5fps]/[6fps]/[3fps]/[1fps]
•
When [System Frequency] is set to [50.00 Hz (PAL)]
[50fps]
¢
/[25fps]/[12.5fps]/[8.3fps]/[6.25fps]/[5fps]/[2.5fps]/[1fps]
¢ Only when set to [FHD/60p]/[FHD/50p]
[Sequence]
[NORMAL]:
Splices pictures together in recording order.
[REVERSE]:
Splices pictures together in reverse recording order.

Panasonic Lumix DMC-GH4 Specifications

General

Sensor Type	Live MOS
Effective Pixels	16.05 Megapixels
Dimensions	132.9 x 93.4 x 83.9 mm
Lens Mount	Micro Four Thirds
Built-in Flash	No
External Flash	Hot shoe
Sensor Size	17.3 x 13.0 mm
ISO Sensitivity	ISO 200-25600
Autofocus System	Contrast Detect AF
Shutter Speed	1/8000 to 60 sec
Continuous Shooting Speed	12 fps
Video Recording	4K (4096 x 2160) at 24 fps, Full HD (1920 x 1080) at 60/30/24 fps
Viewfinder	Electronic (OLED) with 2, 359k dots
Screen	3.0-inch Fully Articulated Touchscreen, 1, 036, 000 dots
Battery Life	Approx. 500 shots (CIPA standard)
Weight	560 g
File Formats	JPEG, RAW, MP4
Connectivity	Wi-Fi, NFC, HDMI, USB 2.0
Storage Media	SD/SDHC/SDXC card
