Panasonic Lumix DMC-GH4 User Manual

6. Recording Suited for the Subject and Scene
154
• Rotate the front/rear dial to display the Exposure Meter. Unsuitable areas of the range are
displayed in red.
• If the exposure is not adequate, the aperture value and the shutter speed turn red and blink
when the shutter button is pressed halfway.
• We recommend using a tripod when the shutter speed is slow.
• When you use a lens with an aperture ring, the aperture ring setting takes priority.
• When the ISO sensitivity is set to [ ], it will switch to [AUTO].
Not available in these cases:
•
When the flash is activated, the fastest shutter speed that can be selected is 1/250th of a
second. (P184)
• The shutter speed slower than 1 second is not available when [Electronic Shutter] is set to
[ON].
Checking/not checking the effects of aperture and shutter speed on the
recording screen
> [Custom] > [Constant Preview] > [ON]/[OFF]
•
Close the flash.
• It can only be used with Manual Exposure Mode.
MENU

Panasonic Lumix DMC-GH4 Specifications

General

Sensor Type	Live MOS
Effective Pixels	16.05 Megapixels
Dimensions	132.9 x 93.4 x 83.9 mm
Lens Mount	Micro Four Thirds
Built-in Flash	No
External Flash	Hot shoe
Sensor Size	17.3 x 13.0 mm
ISO Sensitivity	ISO 200-25600
Autofocus System	Contrast Detect AF
Shutter Speed	1/8000 to 60 sec
Continuous Shooting Speed	12 fps
Video Recording	4K (4096 x 2160) at 24 fps, Full HD (1920 x 1080) at 60/30/24 fps
Viewfinder	Electronic (OLED) with 2, 359k dots
Screen	3.0-inch Fully Articulated Touchscreen, 1, 036, 000 dots
Battery Life	Approx. 500 shots (CIPA standard)
Weight	560 g
File Formats	JPEG, RAW, MP4
Connectivity	Wi-Fi, NFC, HDMI, USB 2.0
Storage Media	SD/SDHC/SDXC card
