Panasonic Lumix DMC-GH4 User Manual

10. Using the Wi-Fi/NFC Function
260
If you are using an iOS device
When scanning the QR code to set up a connection
(If you are reconnecting the camera, steps 1 to 5 are not required)
1 Start “Image App”. (P258)
2 Select [QR code], and then select [OK].
3 Using “Image App”, scan the QR code displayed
on the screen of the camera.
•
If you press [MENU/SET] on the camera, the QR
code will be enlarged. When it is difficult to scan
the QR code, try enlarging it.
4 Install the profile of “IMAGE APP”.
•
A message will be displayed on the browser.
• If the smartphone is locked with a passcode, enter the
passcode to unlock the smartphone.
5 Press the home button to close the browser.
6 Turn on the Wi-Fi function in the setting menu of the smartphone/tablet.
7 Select the SSID displayed on the
screen of the camera.
8 Return to the home screen, and then start “Image
App”. (P258)
•
The connection method differs according to your smartphone/tablet.
IMAGE APP
Panasonic Corporation
Wi-Fi
Wi-Fi
0123456789ABC

Panasonic Lumix DMC-GH4 Specifications

General

Sensor Type	Live MOS
Effective Pixels	16.05 Megapixels
Dimensions	132.9 x 93.4 x 83.9 mm
Lens Mount	Micro Four Thirds
Built-in Flash	No
External Flash	Hot shoe
Sensor Size	17.3 x 13.0 mm
ISO Sensitivity	ISO 200-25600
Autofocus System	Contrast Detect AF
Shutter Speed	1/8000 to 60 sec
Continuous Shooting Speed	12 fps
Video Recording	4K (4096 x 2160) at 24 fps, Full HD (1920 x 1080) at 60/30/24 fps
Viewfinder	Electronic (OLED) with 2, 359k dots
Screen	3.0-inch Fully Articulated Touchscreen, 1, 036, 000 dots
Battery Life	Approx. 500 shots (CIPA standard)
Weight	560 g
File Formats	JPEG, RAW, MP4
Connectivity	Wi-Fi, NFC, HDMI, USB 2.0
Storage Media	SD/SDHC/SDXC card
