Panasonic Lumix DMC-GH4 User Manual

2. Getting Started/Basic Operations
46
∫ About the tilt sensor display
With the tilt sensor displayed, it is easy to correct the tilt of the camera etc.
1 Press [DISP.] to display the tilt sensor.
2 Check the tilt of the camera.
A Horizontal direction:
Correcting tilt to the left
B Vertical direction:
Correcting downward tilt
• When the tilt of the camera is little, the indicator changes to green.
• When recording with a vertical orientation, the display automatically switches to a
vertically orientated display.
• Even after correcting the tilt, there may still be an error of approximately ± 1°.
• When a function button is set to [Level Gauge], the tilt sensor display can be switched on/off by
pressing the function button.
Not available in these cases:
•
Tilt sensor display may not be displayed correctly when this unit is in motion.
• When tilted significantly upwards or downwards to record, the tilt sensor display may not be
displayed correctly, and the Direction Detection Function (P39) may not work correctly.


Panasonic Lumix DMC-GH4 Specifications

General

Sensor Type	Live MOS
Effective Pixels	16.05 Megapixels
Dimensions	132.9 x 93.4 x 83.9 mm
Lens Mount	Micro Four Thirds
Built-in Flash	No
External Flash	Hot shoe
Sensor Size	17.3 x 13.0 mm
ISO Sensitivity	ISO 200-25600
Autofocus System	Contrast Detect AF
Shutter Speed	1/8000 to 60 sec
Continuous Shooting Speed	12 fps
Video Recording	4K (4096 x 2160) at 24 fps, Full HD (1920 x 1080) at 60/30/24 fps
Viewfinder	Electronic (OLED) with 2, 359k dots
Screen	3.0-inch Fully Articulated Touchscreen, 1, 036, 000 dots
Battery Life	Approx. 500 shots (CIPA standard)
Weight	560 g
File Formats	JPEG, RAW, MP4
Connectivity	Wi-Fi, NFC, HDMI, USB 2.0
Storage Media	SD/SDHC/SDXC card
