Panasonic Lumix DMC-GH4 User Manual

5
5
Attach the lens. (P23)
• To attach the lens, align the lens
fitting marks, and rotate the lens in
the direction of the arrow.
6
Open the monitor. (P35)
• Hold the monitor to open it, rotate it
180o to the lens side, and return it to
its original position.
7
Turn the camera on and set the clock.
(P36)
8
Formatting the card (initialization). (P58)
9
Set the mode dial to [¦]. (P41)
• The dial is locked if the mode dial lock
button is depressed. Each press locks/
unlocks the dial.
• The settings of the main functions are
adjusted automatically.



ON
OFF

Panasonic Lumix DMC-GH4 Specifications

General

Sensor Type	Live MOS
Effective Pixels	16.05 Megapixels
Dimensions	132.9 x 93.4 x 83.9 mm
Lens Mount	Micro Four Thirds
Built-in Flash	No
External Flash	Hot shoe
Sensor Size	17.3 x 13.0 mm
ISO Sensitivity	ISO 200-25600
Autofocus System	Contrast Detect AF
Shutter Speed	1/8000 to 60 sec
Continuous Shooting Speed	12 fps
Video Recording	4K (4096 x 2160) at 24 fps, Full HD (1920 x 1080) at 60/30/24 fps
Viewfinder	Electronic (OLED) with 2, 359k dots
Screen	3.0-inch Fully Articulated Touchscreen, 1, 036, 000 dots
Battery Life	Approx. 500 shots (CIPA standard)
Weight	560 g
File Formats	JPEG, RAW, MP4
Connectivity	Wi-Fi, NFC, HDMI, USB 2.0
Storage Media	SD/SDHC/SDXC card
