Panasonic Lumix DMC-GH4 User Manual

3. Easy Recording
88
∫ Setting the light source
You can change the position and size of the light source.
1 Press 3 to display the setting screen.
•
Setting screen can also be displayed by touching in order of [ ] then [ ].
2 Press 3 / 4 / 2 / 1 to move the center position of the light source.
• The position of the light source can also be moved by touching the screen.
• The center of the light source can be moved to the edge of the screen.
3 Adjust the size of the light source by rotating the rear
dial.
•
It can be changed to 4 different sizes.
• The display can also be enlarged/reduced by pinching out/pinching in.
• Pressing [DISP.] will return the light source setting back to the default setting.
4 Press [MENU/SET] to set.
• Display of the recording screen will be delayed more than usual and the screen will look as if
frames are dropping.
Point for when placing the center of the light
source
A more natural appearance can be created by placing
the center of the light source outside the image.

Panasonic Lumix DMC-GH4 Specifications

General

Sensor Type	Live MOS
Effective Pixels	16.05 Megapixels
Dimensions	132.9 x 93.4 x 83.9 mm
Lens Mount	Micro Four Thirds
Built-in Flash	No
External Flash	Hot shoe
Sensor Size	17.3 x 13.0 mm
ISO Sensitivity	ISO 200-25600
Autofocus System	Contrast Detect AF
Shutter Speed	1/8000 to 60 sec
Continuous Shooting Speed	12 fps
Video Recording	4K (4096 x 2160) at 24 fps, Full HD (1920 x 1080) at 60/30/24 fps
Viewfinder	Electronic (OLED) with 2, 359k dots
Screen	3.0-inch Fully Articulated Touchscreen, 1, 036, 000 dots
Battery Life	Approx. 500 shots (CIPA standard)
Weight	560 g
File Formats	JPEG, RAW, MP4
Connectivity	Wi-Fi, NFC, HDMI, USB 2.0
Storage Media	SD/SDHC/SDXC card
