Panasonic PT-RZ670 series

110/200
2.256. DIGITAL LINK SETUP – DUPLEX(DIGITAL LINK) [VXX:DKDI2]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 58h 58h 3Ah
Character A D Z Z ; V X X :
Hexadecimal 44h 4Bh 44h 49h 32h 3Dh 2Bh *1 *3 *5
Character D K D I 2 = + *2 *4 *6
Hexadecimal *7 *9 03h
Character *8 *10
Parameters(*1,*2,*3,*4,*5,*6,*7,*8,*9,*10)
AUTO NEGOTIATION 100BaseTX-Full
Hexadecimal 30h 30h 30h 30h 30h 30h 30h 30h 30h 31h
Character 0 0 0 0 0 0 0 0 0 1
100BaseTX-Half
Hexadecimal 30h 30h 30h 30h 32h
Character 0 0 0 0 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 44h 4Bh 44h 49h 32h
Character V X X : D K D I 2
Hexadecimal 3Dh 2Bh *1 *3 *5 *7 *9 03h
Character = + *2 *4 *6 *8 *10
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× ○ × ○ ○ ○ ○ ○ ○ ×
2.257. Art-Net SETUP [VXX:DANI1]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 58h 58h 3Ah
Character A D Z Z ; V X X :
Hexadecimal 44h 41h 4Eh 49h 31h 3Dh 2Bh *1 *3 *5
Character D A N I 1 = + *2 *4 *6
Hexadecimal *7 *9 03h
Character *8 *10
Parameters(*1,*2,*3,*4,*5,*6,*7,*8,*9,*10)
OFF ON(2.*.*.*)
Hexadecimal 30h 30h 30h 30h 30h 30h 30h 30h 30h 32h
Character 0 0 0 0 0 0 0 0 0 2
ON(10.*.*.*) ON(MANUAL)
Hexadecimal 30h 30h 30h 30h 33h 30h 30h 30h 30h 34h
Character 0 0 0 0 3 0 0 0 0 4
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 44h 41h 4Eh 49h 31h
Character V X X : D A N I 1
Hexadecimal 3Dh 2Bh *1 *3 *5 *7 *9 03h
Character = + *2 *4 *6 *8 *10
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× ○ × ○ ○ ○ ○ ○ ○ ×
2.258. Art-Net SETUP – START ADDRESS [VXX:DANI3]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 58h 58h 3Ah
Character A D Z Z ; V X X :
Hexadecimal 44h 41h 4Eh 49h 33h 3Dh 2Bh *1 *3 *5
Character D A N I 3 = + *2 *4 *6
Hexadecimal *7 *9 03h
Character *8 *10
Parameters(*1,*2,*3,*4,*5,*6,*7,*8,*9,*10)
1 501
Hexadecimal 30h 30h 30h 30h 31h 30h 30h 35h 30h 31h
Character 0 0 0 0 1 0 0 5 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 44h 41h 4Eh 49h 33h
Character V X X : D A N I 3
Hexadecimal 3Dh 2Bh *1 *3 *5 *7 *9 03h
Character = + *2 *4 *6 *8 *10
