Panasonic PT-RZ670 series

198/200
3.2. SELF CHECK INFORMATION
Hexadecimal 02h *1 FEh FEh 03h
Remarks STX ID Command Command ETX
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h *2 FEh *3 *4 *5 *6 *7 *8
STX ID Command response Parameters
Hexadecimal *9 *10 *11 *12 *13 *14 *15 *16 *17 *18 03h
Parameters ETX
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
Parameters(*3,*4,*5,*6,*7,*8,*9,*10,*11,*12,*13,*14,*15,*16,*17,*18)
*3 *4
bit 127 120119 112
*5 *6
bit 111 104103 96
*7 *8
bit 95 8887 80
*9 *10
bit 79 7271 64
*11 *12
bit 63 5655 48
*13 *14
bit 47 4039 32
*15 *16
bit 31 2423 16
*17 *18
bit 15 8 7 0
Bit Factor Description
127
Unused
126
Unused
125
Unused
124
GEOMERTY communication error GEOMERTY IC failure.
123
FM status error FM circuit or DG circuit are failure.
122
Unused
121
Unused
120
FPGA2 communication error
Signal circuit failure.
119
FPGA1 communication error
118
Unused
117
CW error (FPGA)
Color wheel or circuit are failure.
116
CW error (FM)
115
Unused
114
Unused
113
Unused
112
IIC communication error 14(ATM Sensor)
Device failure.
111
IIC communication error 13(HD Base T)
110
Unused
109
IIC communication error 11
(ACCELERATION SENSOR)
Appropriate device malfunction of signal unit.
108
IIC communication error 10(ADC2)
107
IIC communication error 9(ADC1)
106
IIC communication error 8(EDID ANALOG)
105
IIC communication error 7(EDID DIGITAL)
104
Unused
103
Unused
102
Unused
101
Unused
100
IIC communication error 2(EEPROM)
Appropriate device malfunction of signal unit.
99
IIC communication error 1(RTC)
98
Sub microprocessor (R8) communication error Sub microprocessor no response.
97
Unused
96
LD Sub microprocessor communication error LD Sub microprocessor no response.
