Panasonic PT-RZ670 series

85/200
Note:
・When SDI is selected by other than RZ670, ER401 is returned.
・If the combination with input of main-window is not possible, ER402 is returned.
2.190. P IN P - SUB WINDOW – SIZE - INTERLOCKED [SSL]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 53h 53h 4Ch 3Ah
Character A D Z Z ; S S L :
Hexadecimal *1 03h
Character *2
Parameters(*1,*2)
OFF
ON
Hexadecimal 30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 53h 53h 4Ch 3Ah *1 03h
Character S S L : *2
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ × ○ ○ ○ ×
2.191. P IN P - SUB WINDOW – SIZE - VERTICAL [SSV]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 53h 53h 56h 3Ah
Character A D Z Z ; S S V :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters(*1,*2, *3, *4, *5, *6)
10 11 12 13
Hexadecimal 31h 30h 31h 31h 31h 32h 31h 33h
Character 1 0 1 1 1 2 1 3
97 98 99 100
Hexadecimal 39h 37h 39h 38h 39h 39h 31h 30h 30h
Character 9 7 9 8 9 9 1 0 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 53h 53h 56h 3Ah *1 *3 *5 03h
Character S S V : *2 *4 *6
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ × ○ ○ ○ ×
2.192. P IN P - SUB WINDOW – SIZE - HORIZONTAL [SSH]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 53h 53h 48h 3Ah
Character A D Z Z ; S S H :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters(*1,*2, *3, *4, *5, *6)
10 11 12 13
Hexadecimal 31h 30h 31h 31h 31h 32h 31h 33h
Character 1 0 1 1 1 2 1 3
97 98 99 100
Hexadecimal 39h 37h 39h 38h 39h 39h 31h 30h 30h
Character 9 7 9 8 9 9 1 0 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 53h 53h 48h 3Ah *1 *3 *5 03h
Character S S H : *2 *4 *6
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ × ○ ○ ○ ×
