39/200
2.74. INPUT RESOLUTION - TOTAL DOTS [VTD]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 54h 44h 3Ah
Character A D Z Z ; V T D :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
Parameters(*1,*2,*3,*4,*5,*6,*7,*8)
330 331
Hexadecimal 30h 33h 33h 30h 30h 33h 33h 31h
Character 0 3 3 0 0 3 3 1
4094 4095
Hexadecimal 34h 30h 39h 34h 34h 30h 39h 35h
Character 4 0 9 4 4 0 9 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 54h 44h 3Ah *1 *3 *5 *7 03h
Character V T D : *2 *4 *6 *8
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × × ○ × ○ ○ ○ ×
Note:
・An adjustable range changes with input signals/ input resolution.
・When specify a value of less than total dots+30, returns the ER402.
・Can be adjusted only when a signal is input to the [RGB 1 IN] terminal or the [RGB 2 IN] terminal, and HV Sync VIDEO.
2.75. INPUT RESOLUTION - DISPLAY DOTS [VDD]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 44h 44h 3Ah
Character A D Z Z ; V D D :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
Parameters(*1,*2,*3,*4,*5,*6,*7,*8)
300 301
Hexadecimal 30h 33h 30h 30h 30h 33h 30h 31h
Character 0 3 0 0 0 3 0 1
4064 4065
Hexadecimal 34h 30h 36h 34h 34h 30h 36h 35h
Character 4 0 6 4 4 0 6 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 44h 44h 3Ah *1 *3 *5 *7 03h
Character V D D : *2 *4 *6 *8
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × × ○ × ○ ○ ○ ×
Enabled in the case of RGB1/RGB2
Note:
・An adjustable range changes with input signals/ input resolution.
・When specify a value of less than total dots-30, returns the ER402.
2.76. INPUT RESOLUTION - TOTAL LINES [VTL]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 54h 4Ch 3Ah
Character A D Z Z ; V T L :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
Parameters(*1,*2,*3,*4,*5,*6,*7,*8)
155 156
Hexadecimal 30h 31h 35h 35h 30h 31h 35h 36h
Character 0 1 5 5 0 1 5 6
2046 2047
Hexadecimal 24h 30h 34h 36h 32h 30h 34h 37h
Character 2 0 4 6 2 0 4 7
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 54h 4Ch 3Ah *1 *3 *5 *7 03h
Character V T L : *2 *4 *6 *8
