54/200
2.110. BLANKING – LOWER [DBB]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 44h 42h 42h 3Ah
Character A D Z Z ; D B B :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters(*1,*2,*3,*4,*5,*6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
PT-RZ670
597 598 599
Hexadecimal 35h 39h 37h 35h 39h 38h 35h 39h 39h
Character 5 9 7 5 9 8 5 9 9
PT-RW630
396 397 398
Hexadecimal 33h 39h 36h 33h 39h 37h 33h 39h 38h
Character 3 9 6 3 9 7 3 9 8
PT-FRX70C
381 382 383
Hexadecimal 33h 38h 31h 33h 38h 32h 33h 38h 33h
Character 3 8 1 3 8 2 3 8 2
Note:
・From the input signal and aspect, zoom setting conditions, the maximum value will change.
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 44h 42h 42h 3Ah *1 *3 *5 03h
Character D B B : *2 *4 *6
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × × ○ × ○ ○ ○ ×
2.111. BLANKING – RIGHT [DBR]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 44h 42h 52h 3Ah
Character A D Z Z ; D B R :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters(*1,*2,*3,*4,*5,*6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
PT-RZ670
957 958 959
Hexadecimal 39h 35h 37h 39h 35h 38h 39h 35h 39h
Character 9 5 7 9 5 8 9 5 9
PT-RW630
637 638 639
Hexadecimal 36h 33h 37h 36h 33h 38h 36h 33h 39h
Character 6 3 7 6 3 8 6 3 9
PT-FRX70C
509 510 511
Hexadecimal 35h 30h 39h 35h 31h 30h 35h 31h 31h
Character 5 0 9 5 1 0 5 1 1
Note:
・From the input signal and aspect, zoom setting conditions, the maximum value will change.
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 44h 42h 52h 3Ah *1 *3 *5 03h
Character D B R : *2 *4 *6
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × × ○ × ○ ○ ○ ×
