79/200
1366x768p
Hexadecimal 31h 33h 36h 36h 3Ah 30h 37h 36h 38h 3Ah 70h
Character 1 3 6 6 : 0 7 6 8 : p
1400x1050p
Hexadecimal 31h 34h 30h 30h 3Ah 31h 30h 35h 30h 3Ah 70h
Character 1 4 0 0 : 1 0 5 0 : p
1440x900p
Hexadecimal 31h 34h 34h 30h 3Ah 30h 39h 30h 30h 3Ah 70h
Character 1 4 4 0 : 0 9 0 0 : p
1600x900p
Hexadecimal 31h 36h 30h 30h 3Ah 30h 39h 30h 30h 3Ah 70h
Character 1 6 0 0 : 0 9 0 0 : p
1600x1200p
Hexadecimal 31h 36h 30h 30h 3Ah 31h 32h 30h 30h 3Ah 70h
Character 1 6 0 0 : 1 2 0 0 : p
1680x1050p
Hexadecimal 31h 36h 38h 30h 3Ah 31h 30h 35h 30h 3Ah 70h
Character 1 6 8 0 : 1 0 5 0 : p
1920x1080p
Hexadecimal 31h 39h 32h 30h 3Ah 31h 30h 38h 30h 3Ah 70h
Character 1 9 2 0 : 1 0 8 0 : p
1920x1080i
Hexadecimal 31h 39h 32h 30h 3Ah 30h 30h 38h 30h 3Ah 69h
Character 1 9 2 0 : 1 0 8 0 : i
1920x1200p
Hexadecimal 31h 39h 32h 30h 3Ah 31h 30h 30h 30h 3Ah 70h
Character 1 9 2 0 : 1 2 0 0 : p
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 45h 44h 52h 53h 33h
Character V X X : E D R S 3
Hexadecimal 3Dh 2Bh *1 *3 *5 *7 *9 03h
Character = + *2 *4 *6 *8 *10
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ × ○ ○ ○ ×
2.176. HDMI IN – EDID VERTICAL SCAN FREQUENCY [VXX:EDVI3]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 58h 58h 3Ah
Character A D Z Z ; V X X :
Hexadecimal 45h 44h 56h 49h 33h 3Dh 2Bh *1 *3 *5
Character E D V I 3 = + *2 *4 *6
Hexadecimal *7 *9 03h
Character *8 *10
Parameters(*1,*2,*3,*4,*5,*6,*7,*8,*9,*10)
60Hz 50Hz
Hexadecimal 30h 36h 30h 30h 30h 30h 35h 30h 30h 30h
Character 0 6 0 0 0 0 5 0 0 0
48Hz 30Hz
Hexadecimal 30h 34h 38h 30h 30h 30h 33h 30h 30h 30h
Character 0 4 8 0 0 0 3 0 0 0
25Hz 24Hz
Hexadecimal 30h 32h 35h 30h 30h 30h 32h 34h 30h 30h
Character 0 2 5 0 0 0 2 4 0 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 45h 44h 56h 49h 33h
Character V X X : E D V I 3
Hexadecimal 3Dh 2Bh *1 *3 *5 *7 *9 03h
Character = + *2 *4 *6 *8 *10
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ × ○ ○ ○ ×
