35/200
2.63. DIGITAL CINEMA REALITY [OPD]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 50h 44h 3Ah
Character A D Z Z ; O P D :
Hexadecimal *1 03h
Character *2
Parameters(*1,*2)
AUTO OFF
30p/25p FIXED
Hexadecimal 30h 31h 32h
Character 0 1 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 50h 44h 3Ah *1 03h
Character O P D : *2
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × × ○ × ○ ○ ○ ×
2.64. TV-SYSTEM [VSG]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 53h 47h 3Ah
Character A D Z Z ; V S G :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters(*1,*2,*3,*4,*5,*6)
AUTO NTSC
Hexadecimal 41h 54h 31h 41h 54h 32h 4Eh 54h 53h
Character A T 1 A T 2 N T S
NTSC4.43 PAL PAL-M
Hexadecimal 4Eh 34h 34h 50h 41h 4Ch 50h 41h 4Dh
Character N 4 4 P A L P A M
PAL-N SECAM PAL60
Hexadecimal 50h 41h 4Eh 53h 45h 43h 50h 36h 30h
Character P A N S E C P 6 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 53h 47h 3Ah *1 *3 *5 03h
Character V S G : *2 *4 *6
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ × ○ ○ ○ ×
2.65. SHIFT - HORIZONTAL [VTH]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 54h 48h 3Ah
Character A D Z Z ; V T H :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
Parameters(*1,*2,*3,*4,*5,*6,*7,*8)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 30h 30h 31h 30h 30h 30h 32h
Character 0 0 0 0 0 0 0 1 0 0 0 2
4093 4094 4095
Hexadecimal 34h 30h 39h 33h 34h 30h 39h 34h 34h 30h 39h 35h
Character 4 0 9 3 4 0 9 4 4 0 9 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 54h 48h 3Ah *1 *3 *5 *7 03h
Character V T H : *2 *4 *6 *8
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × × ○ × ○ ○ ○ ×
Note:
・Due to the input resolution setting / input signal, the maximum value will change.
・Minimum value : 0, Maximum value : (total dots) - 1.
