Panasonic PT-RZ670 series

86/200
2.193. P IN P - SUB WINDOW – SIZE - BOTH [SSZ]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 53h 53h 5Ah 3Ah
Character A D Z Z ; S S Z :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
Parameters(*1,*2, *3, *4, *5, *6)
10 11 12 13
Hexadecimal 31h 30h 31h 31h 31h 32h 31h 33h
Character 1 0 1 1 1 2 1 3
97 98 99 100
Hexadecimal 39h 37h 39h 38h 39h 39h 31h 30h 30h
Character 9 7 9 8 9 9 1 0 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 53h 53h 5Ah 3Ah *1 *3 *5 03h
Character S S Z : *2 *4 *6
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ × ○ ○ ○ ×
2.194. P IN P - SUB WINDOW - POSITION – VERTICAL [SPV]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 53h 50h 56h 3Ah
Character A D Z Z ; S P V :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
Parameters(*1,*2, *3, *4, *5, *6, *7, *8)
-600 -599 -598
Hexadecimal 2Dh 36h 30h 30h 2Dh 35h 39h 39h 2Dh 35h 39h 38h
Character - 6 0 0 - 5 9 9 - 5 9 8
+598 +599 +600
Hexadecimal 2Bh 35h 39h 38h 2Bh 35h 39h 39h 2Bh 36h 30h 30h
Character + 5 9 8 + 5 9 9 + 6 0 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 53h 50h 56h 3Ah *1 *3 *5 *7 03h
Character S P V : *2 *4 *6 *8
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ × ○ ○ ○ ×
Note:
・Minimum and maximum value of the parameter differing on the menu setting and model, signal.
・When the value specified with the parameter cannot be set up, ER402 is returned.
2.195. P IN P - SUB WINDOW - POSITION – HORIZONTAL [SPH]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 53h 50h 48h 3Ah
Character A D Z Z ; S P H :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
Parameters(*1,*2, *3, *4, *5, *6, *7, *8)
-960 -959 -958
Hexadecimal 2Dh 39h 36h 30h 2Dh 39h 35h 39h 2Dh 369 35h 38h
Character - 9 6 0 - 9 5 9 - 9 5 8
+958 +959 +960
Hexadecimal 2Bh 39h 35h 38h 2Bh 39h 35h 39h 2Bh 39h 36h 30h
Character + 9 5 8 + 9 5 9 + 9 6 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 53h 50h 48h 3Ah *1 *3 *5 *7 03h
Character S P H : *2 *4 *6 *8
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ × ○ ○ ○ ×
Note:
・Minimum and maximum value of the parameter differing on the menu setting and model, signal.
・When the value specified with the parameter cannot be set up, ER402 is returned.
