Panasonic PT-RZ670 series

178/200
Parameters(*1,*2)
Upper left Center left Bottom left Top center Center
Bottom center
Hexadecimal 31h 32h 33h 34h 35h 36h
Character 1 2 3 4 5 6
Upper right Center right Bottom right
Hexadecimal 37h 38h 39h
Character 7 8 9
2.452. QUERY ON-SCREEN DISPLAY - OSD ROTATION [QVX:OSRI1]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 51h 56h 88h 3Ah
Character A D Z Z ; Q V X :
Hexadecimal 4Fh 53h 52h 49h 31h 03h
Character O S R I 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 53h 52h 49h 31h 3Dh 2Bh
Character O S R I 1 = +
Hexadecimal *1 *3 *5 *7 *9 03h
Character *2 *4 *6 *8 *10
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
○ ○ × ○ ○ ○ ○ ○ × ○
Parameters(*1,*2,*3,*4,*5,*6,*7,*8,*9,*10)
OFF CLOCKWISE COUNTER CLOKCWISE
Hexadecimal 30h 30h 30h 30h 30h 30h 30h 30h 30h 31h 30h 30h 30h 30h 32h
Character 0 0 0 0 0 0 0 0 0 1 0 0 0 0 2
2.453. QUERY ON-SCREEN DISPLAY - OSD MEMORY [QVX:OMYI0]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 51h 56h 58h 3Ah
Character A D Z Z ; Q V X :
Hexadecimal 4Fh 4Dh 59h 49h 30h 03h
Character O M Y I 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 4Dh 59h 49h 30h 3Dh 2Bh *1 *3
Character O M Y I 0 = + *2 *4
Hexadecimal *5 *7 *9 03h
Character *6 *8 *10
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
○ ○ × ○ ○ ○ ○ ○ ○ ○
Parameters(*1,*2,*3,*4,*5,*6,*7,*8,*9,*10)
OFF ON
Hexadecimal 30h 30h 30h 30h 30h 30h 30h 30h 30h 31h
Character 0 0 0 0 0 0 0 0 0 1
2.454. QUERY CLOSED CAPTION SETTING [QCC]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 51h 43h 43h 03h
Character A D Z Z ; Q C C
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h *1 03h
Character *2
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
○ × × × ○ ○ ○ ○ ○ ○
Parameters(*1,*2)
OFF CC1 CC2 CC3 CC4
Hexadecimal 30h 31h 32h 33h 34h
Character 0 1 2 3 4
