Panasonic PT-RZ670 series

59/200
2.124. EDGE BLENDING – START – LEFT [VEL]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 45h 4Ch 3Ah
Character A D Z Z ; V E L :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
 Parameters(*1,*2,*3,*4, *5, *6,*7,*8)
0 1919
Hexadecimal 30h 30h 30h 30h 31h 39h 31h 39h
Character 0 0 0 0 1 9 1 9
 Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 45h 4Ch 3Ah *1 *3 *5 *7 03h
Character V E L : *2 *4 *6 *8
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ × ○ ○ ○ ×
Note:
・From the input signal and input resolution , width setting conditions, the maximum value will change.
・The minimum value is 0, and the maximum value be specified in a range of horizontal resolution -1.
2.125. EDGE BLENDING – START – RIGHT [VER]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 45h 52h 3Ah
Character A D Z Z ; V E R :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
 Parameters(*1,*2,*3,*4, *5, *6,*7,*8)
0 1919
Hexadecimal 30h 30h 30h 30h 31h 39h 31h 39h
Character 0 0 0 0 1 9 1 9
 Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 45h 52h 3Ah *1 *3 *5 *7 03h
Character V E R : *2 *4 *6 *8
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ × ○ ○ ○ ×
Note:
・From the input signal and input resolution , width setting conditions, the maximum value will change.
・The minimum value is 0, and the maximum value be specified in a range of horizontal resolution -1.
2.126. EDGE BLENDING – WIDTH - UPPER [VXX:EUWI0]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 58h 58h 3Ah
Character A D Z Z ; V X X :
Hexadecimal 45h 55h 57h 49h 30h 3Dh 2Bh *1 *3 *5
Character E U W I 0 = + *2 *4 *6
Hexadecimal *7 *9 03h
Character *8 *10
 Parameters(*1,*2,*3,*4,*5,*6,*7,*8,*9,*10)
0 1199
Hexadecimal 30h 30h 30h 30h 30h 30h 31h 31h 39h 39h
Character 0 0 0 0 0 0 1 1 9 9
 Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 45h 55h 57h 49h 30h
Character V X X : E U W I 0
Hexadecimal 3Dh 2Bh *1 *3 *5 *7 *9 03h
Character = + *2 *4 *6 *8 *10
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ × ○ ○ ○ ×
Note:
・From the input signal, input resolution and starting position conditions, the maximum value will change.
・The minimum value is 0, and the maximum value be specified in a range of vertical resolution -1.
