Panasonic PT-RZ670 series

170/200
2.432. QUERY P IN P - MAIN WINDOW - SIZE [QSM]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 51h 53h 4Dh 03h
Character A D Z Z ; Q S M
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h *1 *3 2Ch 56h *5 *7 *9 2Ch 48h
Character *2 *4 , V *6 *8 *10 , H
Hexadecimal *11 *13 *15 2Ch 56h 48h *17 *19 *21 03h
Character *12 *14 *16 , H V *18 *20 *22
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
○ × × ○ ○ × ○ ○ ○ ×
Parameters(*1,*2,*3,*4)
・INTERLOCKED
OFF ON
Hexadecimal 4Fh 46h 4Fh 4Eh
Character O F O N
Parameters(*5, *6, *7, *8, *9, *10)
・VERTICAL SIZE
10 11 12
Hexadecimal 30h 31h 30h 30h 31h 31h 30h 31h 32h
Character 0 1 0 0 1 1 0 1 2
98 99 100
Hexadecimal 30h 39h 38h 30h 39h 39h 31h 30h 30h
Character 0 9 8 0 9 9 1 0 0
Parameters(*11, *12, *13, *14, *15, *16)
・HORIZONTAL SIZE
10 11 12
Hexadecimal 30h 31h 30h 30h 31h 31h 30h 31h 32h
Character 0 1 0 0 1 1 0 1 2
98 99 100
Hexadecimal 30h 39h 38h 30h 39h 39h 31h 30h 30h
Character 0 9 8 0 9 9 1 0 0
Parameters(*17, *18, *19, *20, *21, *22)
・HORIZONTAL/VERTICAL SIZE
10 11 12
Hexadecimal 30h 31h 30h 30h 31h 31h 30h 31h 32h
Character 0 1 0 0 1 1 0 1 2
98 99 100
Hexadecimal 30h 39h 38h 30h 39h 39h 31h 30h 30h
Character 0 9 8 0 9 9 1 0 0
2.433. QUERY P IN P - MAIN WINDOW - POSITION [QPA]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 51h 50h 41h 03h
Character A D Z Z ; Q P A
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h *1 *3 *5 *7 2Ch
Character V *2 *4 *6 *8 ,
Hexadecimal 48h *9 *11 *13 *15 03h
Character H *10 *12 *14 *16
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
○ × × ○ ○ × ○ ○ ○ ×
Parameters(*1, *2, *3, *4, *5, *6, *7, *8,)
・VERTICAL POSITION
-364 -363 -362
Hexadecimal 2Dh 33h 36h 34h 2Dh 33h 36h 33h 2Dh 33h 36h 32h
Character - 3 6 4 - 3 6 3 - 3 6 2
+362 +363 +364
Hexadecimal 2Bh 33h 36h 32h 2Bh 33h 36h 33h 2Bh 33h 36h 34h
Character + 3 6 2 + 3 6 3 + 3 6 4
