Panasonic PT-RZ670 series

93/200
2.211. ON-SCREEN DISPLAY - OSD DESIGN [MOD]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Dh 4Fh 44h 3Ah
Character A D Z Z ; M O D :
Hexadecimal *1 03h
Character *2
Parameters(*1,*2)
1 (yellow) 2 (blue) 3 (white) 4 (green) 5 (peach) 6 (brown)
Hexadecimal 30h 31h 32h 33h 34h 35h
Character 0 1 2 3 4 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Dh 4Fh 44h 3Ah *1 03h
Character M O D : *2
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× ○ × ○ ○ ○ ○ ○ ○ ×
2.212. ON-SCREEN DISPLAY - OSD POSITION [ODP]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 44h 50h 3Ah
Character A D Z Z ; O D P :
Hexadecimal *1 03h
Character *2
Parameters(*1,*2)
Upper left Center left Bottom left Top center Center
Hexadecimal 31h 32h 33h 34h 35h
Character 1 2 3 4 5
Bottom center Upper right Center right Bottom right
Hexadecimal 36h 37h 38h 39h
Character 6 7 8 9
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 44h 50h 3Ah *1 03h
Character O D P : *2
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× ○ × ○ ○ ○ ○ ○ ○ ×
2.213. ON-SCREEN DISPLAY - OSD ROTATION [VXX:OSRI1]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 58h 58h 3Ah
Character A D Z Z ; V X X :
Hexadecimal 4Fh 53h 52h 49h 31h 3Dh 2Bh *1 *3 *5
Character O S R I 1 = + *2 *4 *6
Hexadecimal *7 *9 03h
Character *8 *10
Parameters(*1,*2,*3,*4,*5,*6,*7,*8,*9,*10)
OFF CLOCKWISE
Hexadecimal 30h 30h 30h 30h 30h 30h 30h 30h 30h 31h
Character 0 0 0 0 0 0 0 0 0 1
COUNTER CLOKCWISE
Hexadecimal 30h 30h 30h 30h 32h
Character 0 0 0 0 2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 4Fh 53h 52h 49h 31h
Character V X X : O S R I 1
Hexadecimal 3Dh 2Bh *1 *3 *5 *7 *9 03h
Character = + *2 *4 *6 *8 *10
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ ○ ○ ○ ○ ×
