Panasonic PT-RZ670 series

55/200
2.112. BLANKING – LEFT [DBL]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 44h 42h 4Ch 3Ah
Character A D Z Z ; D B L :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
 Parameters(*1,*2,*3,*4,*5,*6)
0 1 2
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
PT-RZ670
957 958 959
Hexadecimal 39h 35h 37h 39h 35h 38h 39h 35h 39h
Character 9 5 7 9 5 8 9 5 9
PT-RW630
637 638 639
Hexadecimal 36h 33h 37h 36h 33h 38h 36h 33h 39h
Character 6 3 7 6 3 8 6 3 9
PT-FRX70C
509 510 511
Hexadecimal 35h 30h 39h 35h 31h 30h 35h 31h 31h
Character 5 0 9 5 1 0 5 1 1
 Note:
・From the input signal and aspect, zoom setting conditions, the maximum value will change.
 Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 44h 42h 4Ch 3Ah *1 *3 *5 03h
Character D B L : *2 *4 *6
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × × ○ × ○ ○ ○ ×
2.113. CUSTOM MASKING [VXX:MSKI1]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 58h 58h 3Ah
Character A D Z Z ; V X X :
Hexadecimal 4Dh 53h 4Bh 49h 31h 3Dh 2Bh *1 *3 *5
Character M S K I 1 = + *2 *4 *6
Hexadecimal *7 *9 03h
Character *8 *10
 Parameters(*1,*2,*3,*4,*5,*6,*7,*8,*9,*10)
OFF PC-1
Hexadecimal 30h 30h 30h 30h 30h 30h 30h 30h 30h 31h
Character 0 0 0 0 0 0 0 0 0 1
PC-2 PC-3
Hexadecimal 30h 30h 30h 30h 32h 30h 30h 30h 30h 33h
Character 0 0 0 0 2 0 0 0 0 3
 Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 4Dh 53h 4Bh 49h 31h
Character V X X : M S K I 1
Hexadecimal 3Dh 2Bh *1 *3 *5 *7 *9 03h
Character = + *2 *4 *6 *8 *10
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ × ○ ○ ○ ×
 Note:
・Other than RZ670, ER401 is returned.
・Returns the ER401 if it is not activation.
