19/200
2.8. TEST PATTERN [OTS]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 54h 53h 3Ah
Character A D Z Z ; O T S :
Hexadecimal *1 *3 03h
Character *2 *4
Parameters(*1,*2,*3,*4)
OFF White Black Flag Reversed Flag
Hexadecimal 30h 30h 30h 31h 30h 32h 30h 33h 30h 34h
Character 0 0 0 1 0 2 0 3 0 4
Window Reversed Window Focus(White)
Color bar (vertical) Convergence
Hexadecimal 30h 35h 30h 36h 31h 31h 30h 38h 31h 31h
Character 0 5 0 6 1 1 0 8 1 1
Red Green Blue Cyan Magenta
Hexadecimal 32h 32h 32h 33h 32h 34h 32h 38h 32h 39h
Character 2 2 2 3 2 4 2 8 2 9
Yellow CW INDEX Color bar (Side) 16:9/4:3 Focus(Red)
Hexadecimal 33h 30h 34h 31h 35h 31h 35h 39h 37h 30h
Character 3 0 4 1 5 1 5 9 7 0
Focus(Green) Focus(Blue) Focus(Cyan) Focus(Magenta) Focus(Yellow)
Hexadecimal 37h 31h 37h 32h 37h 33h 37h 34h 37h 35h
Character 7 1 7 2 7 3 7 4 7 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 54h 53h 3Ah *1 *3 03h
Character O T S : *2 *4
Acceptability
SECURITY STANDBY ECO
STANDBY
NO SIGNAL SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ × ○ ○ ○ ×
2.9. ON SCREEN [OOS]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 4Fh 53h 3Ah *1 03h
Character A D Z Z ; O O S : *2
Parameters(*1,*2)
OSD OFF OSD ON
Hexadecimal 30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 4Fh 53h 3Ah *1 03h
Character O O S : *2
Acceptability
SECURITY STANDBY ECO
STANDBY
NO SIGNAL SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ ○ ○ ○ ○ ○ ×
Note:
・If the logo is being displayed is invalid.
2.10. MENU KEY [OMN]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 4Dh 4Eh 03h
Character A D Z Z ; O M N
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 4Dh 4Eh 03h
Character O M N
Acceptability
SECURITY STANDBY ECO
STANDBY
NO SIGNAL SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
○ × × ○ ○ ○ ○ ○ ○ ○
