Panasonic PT-RZ670 series

40/200
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × × ○ × ○ ○ ○ ×
Enabled in the case of RGB1/RGB2
 Note:
・An adjustable range changes with input signals/ input resolution.
・When specify a value of less than DISPLAY LINES+10, returns the ER402.
2.77. INPUT RESOLUTION - DISPLAY LINES [VDL]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 44h 4Ch 3Ah
Character A D Z Z ; V D L :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
 Parameters(*1,*2,*3,*4,*5,*6,*7,*8)
150 151
Hexadecimal 30h 31h 35h 30h 30h 31h 35h 31h
Character 0 1 5 0 0 1 5 1
2036 2037
Hexadecimal 32h 30h 33h 36h 32h 30h 33h 37h
Character 2 0 3 6 2 0 3 7
 Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 44h 4Ch 3Ah *1 *3 *5 *7 03h
Character V D L : *2 *4 *6 *8
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × × ○ × ○ ○ ○ ×
Enabled in the case of RGB1/RGB2
 Note:
・An adjustable range changes with input signals/ input resolution.
・When specify a value of less than DISPLAY LINES-10, returns the ER402.
2.78. CLAMP POSITION [VLT]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 4Ch 54h 3Ah
Character A D Z Z ; V L T :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
 Parameters(*1,*2,*3,*4,*5,*6)
1 2
Hexadecimal 30h 30h 31h 30h 30h 32h
Character 0 0 1 0 0 2
254 255
Hexadecimal 32h 35h 34h 32h 35h 35h
Character 2 5 4 2 5 5
 Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 4Ch 54h 3Ah *1 *3 *5 03h
Character V L T : *2 *4 *6
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× × × ○ × ○ ○ ○ ×
 Note:
・It is available only when RGB1 or RGB2 is selected. In other case returns the ER401.
2.79. KEYSTONE [OKS]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 4Bh 53h 3Ah
Character A D Z Z ; O K S :
Hexadecimal *1 *3 *5 03h
Character *2 *4 *6
 Parameters(*1,*2,*3,*4,*5,*6)
-127 -126 -125
Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h
Character 0 0 0 0 0 1 0 0 2
+125 +126 +127
Hexadecimal 32h 35h 32h 32h 35h 33h 32h 35h 34h
Character 2 5 2 2 5 3 2 5 4
