Panasonic PT-RZ670 series

172/200
Parameters(*17, *18, *19, *20, *21, *22)
・HORIZONTAL/VERTICAL SIZE
10 11 12
Hexadecimal 30h 31h 30h 30h 31h 31h 30h 31h 32h
Character 0 1 0 0 1 1 0 1 2
98 99 100
Hexadecimal 30h 39h 38h 30h 39h 39h 31h 30h 30h
Character 0 9 8 0 9 9 1 0 0
2.436. QUERY P IN P - SUB WINDOW - POSITION [QPS]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 51h 50h 53h 3Ah
Character A D Z Z ; Q P S :
Hexadecimal *1 03h
Character *2
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h *1 *3 *5 *7 2Ch
Character V *2 *4 *6 *8 ,
Hexadecimal 48h *9 *11 *13 *15 03h
Character H *10 *12 *14 *16
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
○ × × ○ ○ × ○ ○ ○ ×
Parameters(*1, *2, *3, *4, *5, *6, *7, *8,)
・VERTICAL POSITION
-364 -363 -362
Hexadecimal 2Dh 33h 36h 34h 2Dh 33h 36h 33h 2Dh 33h 36h 32h
Character - 3 6 4 - 3 6 3 - 3 6 2
+362 +363 +364
Hexadecimal 2Bh 33h 36h 32h 2Bh 33h 36h 33h 2Bh 33h 36h 34h
Character + 3 6 2 + 3 6 3 + 3 6 4
Parameters(*9, *10, *11, *12, *13, *14, *15, *16)
・HORIZONTAL POSITION
-651 -650 -649
Hexadecimal 2Dh 36h 35h 31h 2Dh 36h 35h 30h 2Dh 36h 34h 39h
Character - 6 5 1 - 6 5 0 - 6 4 9
+649 +650 +651
Hexadecimal 2Bh 36h 34h 39h 2Bh 36h 35h 30h 2Bh 36h 35h 31h
Character + 6 4 9 + 6 5 0 + 6 5 1
Note:
・Value of the parameter depends on the setting menu and model, input signal.
2.437. QUERY P IN P - SUB WINDOW - CLOCK PHASE [QVX:SCPI0]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 51h 56h 58h 3Ah
Character A D Z Z ; Q V X :
Hexadecimal 53h 43h 50h 49h 30h 03h
Character S C P I 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 53h 43h 50h 49h 30h 3Dh 2Bh *1 *3
Character S C P I 0 = + *2 *4
Hexadecimal *5 *7 *9 03h
Character *6 *8 *10
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
○ × × ○ ○ × ○ ○ ○ ×
Parameters(*1,*2,*3,*4,*5,*6,*7,*8,*9,*10)
0 1
Hexadecimal 30h 30h 30h 30h 30h 30h 30h 30h 30h 31h
Character 0 0 0 0 0 0 0 0 0 1
30 31
Hexadecimal 30h 30h 30h 33h 30h 30h 30h 30h 33h 31h
Character 0 0 0 3 0 0 0 0 3 1
