42/200
2.82. GEOMETRY [VXX:GMMI0]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 58h 58h 3Ah
Character A D Z Z ; V X X :
Hexadecimal 47h 4Dh 4Dh 49h 30h 3Dh 2Bh *1 *3 *5
Character G M M I 0 = + *2 *4 *6
Hexadecimal *7 *9 03h
Character *8 *10
Parameters(*1,*2,*3,*4,*5,*6,*7,*8,*9,*10)
OFF KEYSTONE
Hexadecimal 30h 30h 30h 30h 30h 30h 30h 30h 30h 31h
Character 0 0 0 0 0 0 0 0 0 1
CURVED PC-1
Hexadecimal 30h 30h 30h 30h 32h 30h 30h 30h 30h 33h
Character 0 0 0 0 2 0 0 0 0 3
PC-2 PC-3
Hexadecimal 30h 30h 30h 30h 34h 30h 30h 30h 30h 35h
Character 0 0 0 0 4 0 0 0 0 5
CORNER-CORRECTION
Hexadecimal 30h 30h 30h 31h 30h
Character 0 0 0 1 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 47h 4Dh 4Dh 49h 30h
Character V X X : G M M I 0
Hexadecimal 3Dh 2Bh *1 *3 *5 *7 *9 03h
Character = + *2 *4 *6 *8 *10
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× ○ × ○ ○ × ○ ○ ○ ×
Note:
・Other than RZ670 model, ER401 is returned.
2.83. GEOMETRY - KEYSTONE - LENS THROW RATIO [VXX:GMKS0]
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 58h 58h 3Ah
Character A D Z Z ; V X X :
Hexadecimal 47h 4Dh 4Bh 53h 30h 3Dh 2Bh *1 *3 *5
Character G M K S 0 = + *2 *4 *6
Hexadecimal *7 03h
Character *8
Parameters(*1,*2,*3,*4,*5,*6,*7,*8)
0.7 0.8
Hexadecimal 30h 30h 2Eh 37h 30h 30h 2Eh 38h
Character 0 0 . 7 0 0 . 8
16.4 16.5
Hexadecimal 31h 36h 2Eh 34h 31h 36h 2Eh 35h
Character 1 6 . 4 1 6 . 5
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 47h 4Dh 4Bh 53h 30h
Character V X X : G M K S 0
Hexadecimal 3Dh 2Bh *1 *3 *5 *7 03h
Character = + *2 *4 *6 *8
Acceptability
SECURITY STANDBY ECO
STANDBY
NO
SIGNAL
SHUTTER FREEZE TEST
PATTERN
REMOTE2 P IN P LENS
HOME
× ○ × ○ ○ × ○ ○ ○ ×
Note:
・Other than RZ670, ER401 is returned.
・Character that can be specified, only numbers and period.
・Will be set to 0.7 to 16.5 in 0.1 increments.
