7.2. Part Location
7.2.1. SMPS P.C.B.
Fig. 1 SMPS P.C.B.
Thermistor:
TH5860
Photocoupler:
PC5720
AC Inlet:
P5701
Fuse:
F1
Photocoupler:
PC5702, PC5799
Switching IC:
IC5701
Switching IC:
IC5799
Transformer:
T5701
Rectifier:
D5801, D5802
Connector:
CN5802
