9.1. Disassembly Flow Chart
9.23. Rear Panel
9.22. CD Servo P.C.B.
9.3. Top Cabinet
9.21. CD Mechanism Unit
(DLS6C)
9.16. Switching Regulator
IC (IC5701)
9.17. Rectifier Diode
(D5702)
9.19. Regulator Diode
(D5802)
9.18. Regulator Diode
(D5801)
9.20. Regulator Diode
(D5803)
9.5. Front Panel
Assembly
9.6. Panel P.C.B.
9.9. USB P.C.B.
9.10. CD Lid
9.7. Remote Sensor
P.C.B.
9.11. Main P.C.B.
9.13. D-Amp P.C.B.
9.14. Audio Digital Amp
IC (IC5900)
9.15. SMPS P.C.B.
9.12. Regulator
IC (IC2701)
9.4. Tuner P.C.B.
9.24. Voltage Selector
P.C.B. (For PH only)
9.8. CD Open
Button P.C.B.
