6.3. Reliability Test Mode (CD Mechanism Unit (DLS6C))
Below is the process flow chart of the aging test for the CD Mechanism Unit (DLS6C).
Fig. 1. Reliability Test (Loading)
Fig. 2. Reliability Test (Traverse)
Fig. 3. Reliability Test (Combination)
OPEN
Operation
OPEN wait
fot 1 s
CLOSE
Operation
CLOSE wait
for 5s
Count up
First Track
Access
First Track
Play 5 s
Last Track
Access
Last Track
Play 5 s
Count up
First Track
Access
First Track
Play 5 s
Last Track
Access
Last Track
Play 5 s
Open
Operation
Open wait
for 1 s
CLOSE
Operation
Count up
