1.6. Safety Parts Information
Safety Parts List:
There are special components used in this equipment which are important for safety.
These parts are marked by in the Schematic Diagrams, Exploded View & Replacement Parts List. It is essential that these
critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards. Do not modify the
original design without permission of manufacturer.
Safety Ref No. Part No. Part Name & Description Remarks
14 REXX1122-K 1P BLK WIRE (VOLTAGE SELECTOR - SMPS)
15 REXX1123-K 1P RED WIRE (VOLTAGE SELECTOR - SMPS)
22 RGR0439C-C1 REAR PANEL
41 RKM0702-K TOP CABINET
301 RAE1037Z-V TRAVERSE ASS'Y
A2 K2CQ2YY00119 AC CORD
A3 RQT9800-M O/I BOOK (Sp/En)
PCB10 REP4908G SMPS P.C.B. (RTL)
PCB11 REP4908G VOLTAGE SELECTOR P.C.B. (RTL)
DZ5701 D4EAY511A127 VARISTOR (E.S.D)
S5701 K0ABCA000007 VOLT ADJ
L5701 G0B183J00002 LINE FILTER
L5702 G0B183J00002 LINE FILTER
T5701 G4DYZ0000070 TRANSFORMER
T5751 G4DYZ0000064 TRANSFORMER
T6000 G4DYA0000214 TRANSFORMER
TH5861 D4CCY1040001 THERMISTOR
PC5701 B3PBA0000579 PHOTO COUPLER
PC5702 B3PBA0000579 PHOTO COUPLER
PC5720 B3PBA0000579 PHOTO COUPLER
PC5799 B3PBA0000579 PHOTO COUPLER
F1 K5D103BNA005 FUSE
P5701 K2AA2B000011 AC INLET
R5708 D0GF155JA048 1.5M 1/4W
R5709 D0GF155JA048 1.5M 1/4W
R5901 ERG2SJ471E 470 2W
R5902 ERG2SJ471E 470 2W
R5903 ERG2SJ471E 470 2W
R5904 ERG2SJ471E 470 2W
R5905 ERG2SJ471E 470 2W
R5906 ERG2SJ471E 470 2W
R5907 ERG2SJ471E 470 2W
R5908 ERG2SJ471E 470 2W
C5700 F1BAF471A013 470pF
C5701 F0CAF104A105 0.1uF
C5702 F0CAF104A105 0.1uF
C5703 F0CAF104A105 0.1uF
C5704 F1BAF471A013 470pF
C5705 F1BAF471A013 470pF
C5707 F1BAF471A013 470pF
C5708 F1BAF471A013 470pF
