16 Appendix Information of Schematic Diagram
16.1. Voltage & Waveform Chart
Note:
• Indication Voltage Values are in standard values for the unit measured by the DC electronic circuit tester (high-impedance) with
the chassis taken as standard.
Therefore, there may exist some errors in voltage values, depending on the internal impedance of the DC circuit tester.
• Circuit voltage and waveform described herein shall be regarded as reference information when probing defect point because it
may differ from actual measuring value due to difference of Measuring instrument and its measuring condition and product itself.
16.1.1. Main P.C.B. (1/7)
REF NO.
MODE 1234567891011121314151617181920
TUNER
0 1.5 0 3.0
3.3 0 3.0 3.3 0
3.3
3.3 0 1.4 0.3 2.8 2.8 3.3 0 0 0
REF NO.
MODE 1234567891011121314
CD PLAY 2.4 0 4.7 3.3 0 1.6 1.7 1.6 1.3 0 0 0 2.4 2.4
STANDBY 2.4 0 4.8 3.3 0 1.6 1.7 1.6 1.5 0 0 0 2.4 2.4
REF NO.
MODE 12345678910111213141516
AUX IN 2.8 0 3.0 0 2.0 00003.002.83.02.0012.0
STANDBY 2.8 0 3.0 0 2.0 00003.002.83.02.0012.0
REF NO.
MODE 12345
POWER ON 3.3 0 3.3 0 1.8
STANDBY 3.3 0 3.3 0 1.8
REF NO.
MODE 12345
POWER ON 3.3 0 3.3 5.1 5.1
STANDBY 3.3 0 3.3 5.1 5.1
REF NO.
MODE 1234567891011121314151617181920
CD PLAY 1.8 0 0 3.3 0 0 1.6 1.6 1.6 1.8 3.3 0 1.6 1.8 3.3 3.3 3.3 1.8 3.3 0
STANDBY 1.8 0 0 3.3 0 0 1.6 1.6 1.6 1.8 3.3 0 1.6 1.8 3.3 3.3 3.3 1.8 3.3 0
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
CD PLAY 3.3 3.3 3.3 0 0 12.0 000012.0 0 0 0 12.0 0 0 3.3 0 0
STANDBY 3.3 3.3 3.3 0 0 12.0 000012.0 0 0 0 12.0 0 0 3.3 0 0
REF NO.
MODE 41 42 43 44 45 46 47 48
CD PLAY 0 0 1.6 1.7 0.8 0 1.8 1.6
STANDBY 0 0 1.6 1.7 0.8 0 1.8 1.6
REF NO.
MODE 1234567891011121314151617181920
POWER ON 1.3 0.7 1.0 0 0.8 0 0 3.3 3.3 0 0 1.6 1.5 0 1.3 1.7 3.3 1.8 3.3 3.3
STANDBY 1.3 0.7 1.0 0 0.8 0 0 3.3 3.3 0 0 1.6 1.5 0 1.3 1.7 3.3 1.8 3.3 3.3
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
POWER ON 3.3 0 0 4.8 3.3 3.3 0 3.3 3.3 1.8 0 0 5.0 3.3 3.3 3.3 1.8 3.3 0 3.3
STANDBY 3.3 0 0 4.8 3.3 3.3 0 3.3 3.3 1.8 0 0 5.0 3.3 3.3 3.3 1.8 3.3 0 3.3
IC2006
SA-MAX200PH MAIN P.C.B
.
IC2000
IC2006
IC2005
IC2005
IC2005
IC2001
IC2002
IC2003
IC2004
