Panasonic SA-MAX200PH - Main P.C.B. (2;7)

96
16.1.2. Main P.C.B. (2/7)
REF NO.
MODE 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
POWER ON 3.3 3.3 3.3 0 0 3.3 3.3 3.3 0 3.3 0 0 3.3 3.2 0 0 3.3 3.3 3.3 3.3
STANDBY 3.3 3.3 3.3 0 0 3.3 3.3 3.3 0 3.3 0 0 3.3 3.2 0 0 3.3 3.3 3.3 3.3
REF NO.
MODE 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
POWER ON 3.3 3.3 0 3.3 3.3 3.3 3.3 3.3 3.3 0 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 0 3.3
STANDBY 3.3 3.3 0 3.3 3.3 3.3 3.3 3.3 3.3 0 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 0 3.3
REF NO.
MODE 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100
POWER ON 3.3 3.3 3.3 3.3 0 3.3 0 1.6 3.3 3.3 0 0.4 0.6 3.3 1.7 0 2.6 3.3 3.0 3.3
STANDBY 3.3 3.3 3.3 3.3 0 3.3 0 1.6 3.3 3.3 0 0.4 0.6 3.3 1.7 0 2.6 3.3 3.0 3.3
REF NO.
MODE 12345678
POWER ON 00003.33.303.3
STANDBY 00003.33.303.3
REF NO.
MODE 1234567891011121314151617181920
CD PLAY 000000.61.11.83.301.61.003.33.33.33.33.33.33.3
STANDBY 000000.71.11.83.301.61.003.33.33.33.33.33.33.3
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
CD PLAY 3.3 1.7 1.6 0.8 0 0 1.2 1.8 1.2 1.6 1.6 0 0 3.3 3.3 0 3.3 1.6 1.6 1.6
STANDBY 3.3 1.7 1.6 0.8 0 0 1.2 1.8 1.2 1.6 1.6 0 0 3.3 3.3 0 3.3 1.6 1.6 1.6
REF NO.
MODE 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56
CD PLAY 1.6 1.6 1.6 1.6 1.6 1.6 0 1.6 1.6 3.3 0 1.8 0 1.6 0 1.4
STANDBY 1.6 1.6 1.6 1.6 1.6 1.6 0 1.6 1.6 3.3 0 1.8 0 1.6 0 1.4
REF NO.
MODE 1 2 3
POWER ON 0 3.3 5.4
STANDBY 0 3.3 5.4
REF NO.
MODE 12345678
POWER ON 8.5 1.6 1.6 0 1.6 1.6 8.8 15.3
STANDBY 8.5 1.6 1.6 0 1.6 1.6 8.8 15.3
REF NO.
MODE 12345678910
POWER ON 18.7 37.4 5.0 2.0 0.5 0 0.8 0.9 0 12.6
STANDBY 18.7 37.4 4.5 2.2 0.5 0 0.8 0.8 0 12.6
IC2011
SA-MAX200PH MAIN P.C.B
.
IC2006
IC2010
IC2008
IC2008
IC2009
IC2006
IC2006
IC2007
IC2008
