14.1.2. Main P.C.B. (2/4)
REF NO.
MODE 41424344
PLAY 3.3 3.3 0 3.3
STANDBY 3.3 3.3 0 3.3
REF NO.
MODE 12345678910
PLAY 10.9 39.5 3.1 2.1 0.5 0 0.8 0.7 0 4.7
STANDBY 10.9 39.5 3.1 2.1 0.5 0 0.8 0.7 0 4.7
REF NO.
MODE 12345678
PLAY 8.6 1.6 1.6 0 1.6 1.6 8.6 15.3
STANDBY 8.6 1.6 1.6 0 1.6 1.6 8.6 15.3
REF NO.
MODE 12345678910
PLAY 21.3 39.5 3.1 2.1 0.5 0 0.8 0.7 0 15.2
STANDBY 21.3 39.5 3.1 2.1 0.5 0 0.8 0.7 0 15.2
REF NO.
MODE 1 2 3
PLAY 0 3.3 5.5
STANDBY 0 3.3 5.5
REF NO.
MODE 1234
PLAY 3.3 0 1.6 3.3
STANDBY 3.3 0 1.6 3.3
REF NO.
MODE 1 2 3
PLAY 0 3.3 5
STANDBY 0 3.3 5
REF NO.
MODE 1234567891011121314151617181920
PLAY 12.2 12.1 1.2 0 1.7 1.7 3.3 000007.83.303.33.3000
STANDBY 12.2 12.1 1.2 0 1.7 1.7 3.3 000007.83.303.33.3000
REF NO.
MODE 2122232425262728293031323334353637383940
PLAY 3.3 12 30.1 30.1 0 0 19 19 39.5 39.5 39.5 19 0 0 19 39.5 39.5 39.5 19 19
STANDBY 3.3 12 30.1 30.1 0 0 19 19 39.5 39.5 39.5 19 0 0 19 39.5 39.5 39.5 19 19
REF NO.
MODE
41 42 43 44
PLAY 0 0 30.1 30
STANDBY 0 0 30.1 30
REF NO.
MODE 1234567891011121314151617181920
PLAY 12 12 1.1 3.3 1.7 1.7 3.3 3.3 00007.71.71.73.33.33.303.3
STANDBY 12 12 1.1 3.3 1.7 1.7 3.3 3.3 00007.71.71.73.33.33.303.3
SA-MAX3500PU MAIN P.C.B.
IC1202
IC2101
IC2102
IC2103
IC2104
IC2107
IC2108
IC3001
IC3101
IC3001
IC3001
REF NO.
MODE 2122232425262728293031323334353637383940
PLAY 0 12 30 30 0 0 19.1 19.1 39.5 39.5 39.5 19.1 0 0 19.1 39.5 39.5 39.5 19.1 19.4
STANDBY 0 12 30 30 0 0 19.1 19.1 39.5 39.5 39.5 19.1 0 0 19.1 39.5 39.5 39.5 19.1 19.4
IC3101
