RX1206 D1H81014A042 RESISTOR NETWORK 1
RX1207 D1H81014A042 RESISTOR NETWORK 1
RX5001 D1H81034A042 RESISTOR NETWORK 1
OSCILLATORS
X1001 H0J169500045 OSCILLATOR 1
X1002 H0A327200191 OSCILLATOR 1
X4001 H0J245500110 OSCILLATOR 1
PRINTED CIRCUIT
BOARDS
PCB3 TNPA6750 TUNER P.C.B. 1 (RTL)
CAPACITORS
C51 F1H1H102B047 1000pF 50V 1
C60 F1H1H6R0B050 6pF 50V 1
C61 F1H1H104B047 0.1uF 50V 1
C62 F1H1H104B047 0.1uF 50V 1
C63 F1H1H6R0B050 6pF
50V 1
C65 D0GBR00J0004 0 1/10W 1
C66 F1H1H330B052 33pF 50V 1
C67 F1H1H3R0B050 3pF 50V 1
C6108 F1H1A1050040 1uF
10V 1
C6109 F1H1A1050040 1uF 10V 1
C6217 F1H1A1050040 1uF 10V 1
CONNECTORS
CN51 K1MN10A00011 10P CONNECTOR 1
INTEGRATED CIR-
CUITS
IC52 VUEALLPT091 IC 1 (E.S.D)
JACKS
JK51 K4ZZ02000103 JK 1
JK6002 K2HA2YYA0009 JK 1
INDUCTORS
L51 G1CR18JA0020 INDUCTOR 1
L54 G1C1R0MA0204 INDUCTOR 1
L55 F1H1H3R0B050 3pF 50V 1
LB51 J0JYC0000656 INDUCTOR 1
LB52 J0JYC0000118 INDUCTOR 1
LB6119 J0JBC0000010 INDUCTOR 1
LB6120 J0JBC0000010 INDUCTOR 1
RESISTORS
R51 D0GB221JA065 220 1/10W 1
R52 D0GB221JA065 220 1/10W 1
R55 D0GAR00J0005 0 1/16W 1
R56 D0GBR00J0004 0 1/10W 1
R57 D0GA102JA023 1K
1/16W 1
R59 D0GB222JA065 2.2K 1/10W 1
R60 D0GB221JA065 220 1/10W 1
R61 D0GBR00J0004 0 1/10W 1
R6106 D0GB472JA065 4.7K 1/10W
1
R6107 D0GB472JA065 4.7K 1/10W 1
R6114 D0GBR00J0004 0 1/10W 1
R6117 D0GB103JA065 10K 1/10W 1
R6118 D0GB103JA065 10K 1/10W 1
R6135 D0GBR00J0004 0 1/10W
1
R6136 D0GBR00J0004 0 1/10W 1
VARISTORS
VA51 J0ZZB0000202 VARISTOR 1
PRINTED CIRCUIT
BOARDS
PCB4 TNPA6755AC PANEL P.C.B. 1 (RTL)
CAPACITORS
C6001 F1H1C104A178 0.1uF 16V 1
C6002 F1H0J1060006 10uF 6.3V 1
C6200 F1H1H101B052 100pF 50V
1
C6201 F1H1H101B052 100pF 50V 1
C6209 F1H1H101B052 100pF 50V 1
C6210 F1H1H101B052 100pF 50V 1
C6300 F1J1E105A287 1uF 25V 1
C6301 F1J1H105A918 1uF
50V 1
C6302 F1J1E105A287 1uF 25V 1
C6303 F1H1H104B047 0.1uF 50V 1
C6304 F1H1H104B047 0.1uF 50V 1
C6305 F2A1V470B125 47uF 35V
1
C6306 F1J1E105A287 1uF 25V 1
C6307 F1H1H104B047 0.1uF 50V 1
Safety Ref.
No.
Part No. Part Name &
Description
Qty Remarks
C6311 F1H1H105B027 1uF 50V 1
C6312 F1H1H105B027 1uF 50V 1
C6330 F1H1H105B027 1uF 50V 1
C6331 F1H1H105B027 1uF 50V 1
CONNECTORS
CN6203 K1ZZ00000832 CONNECTOR 1
CN6204 K1ZZ00000832 CONNECTOR 1
DIODES
D6004 B3ABA0000977 DIODE 1
D6006 B3AAA0001246 DIODE 1
D6007 B3ABA0000977 DIODE 1
D6008 B3AEA0000203 DIODE 1
D6009 B3AAA0001246 DIODE 1
D6010 B3ABA0000977 DIODE 1
D6011 B3AEA0000203 DIODE 1
D6012 B3AAA0001246 DIODE 1
D6013 B3ABA0000977 DIODE 1
D6015 B3AAA0001246 DIODE 1
D6020 B3AEA0000203 DIODE 1
D6022 B3AEA0000203 DIODE 1
D6301 B0ADDH000009 DIODE 1
D6302 B0ADDH000009 DIODE 1
FL DISPLAY
DP6300 A2BB00000186 FL DISPLAY 1
INTEGRATED CIR-
CUITS
IC6001 C0JBAZ002990 IC 1 (E.S.D)
REMOTE SENSOR
IR6301 B3RAD0000226 REMOTE SENSOR 1
INDUCTORS
LB6001 J0JYC0000656 INDUCTOR 1
CONNECTORS
P6200 K1MN22B00014 22P CONNECTOR 1
TRANSISTORS
Q6301 B1HFCDE00002 TRANSISTOR 1
Q6302 B1HFCDE00002 TRANSISTOR 1
QR6004 B1GBCFGG0030 TRANSISTOR 1
QR6005 B1GBCFGG0030 TRANSISTOR 1
QR6006 B1GBCFGG0030 TRANSISTOR 1
QR6007 B1GBCFGG0030 TRANSISTOR 1
QR6008 B1GBCFGG0030 TRANSISTOR 1
QR6009 B1GBCFGG0030 TRANSISTOR 1
QR6010 B1GBCFGG0030 TRANSISTOR 1
QR6011 B1GBCFGG0030 TRANSISTOR 1
QR6012 B1GBCFGG0030 TRANSISTOR 1
QR6013 B1GBCFGG0030 TRANSISTOR 1
QR6014 B1GBCFGG0030 TRANSISTOR 1
QR6015 B1GBCFGG0030 TRANSISTOR 1
RESISTORS
R6004 D0GB101JA065 100 1/10W 1
R6006 D0GB151JA065 150 1/10W 1
R6007 D0GB101JA065 100 1/10W 1
R6008 D0GB820JA065 82
1/10W 1
R6009 D0GB151JA065 150 1/10W 1
R6010 D0GB101JA065 100 1/10W 1
R6011 D0GB820JA065 82 1/10W 1
R6012 D0GB151JA065 150 1/10W
1
R6013 D0GB101JA065 100 1/10W 1
R6015 D0GB151JA065 150 1/10W 1
R6020 D0GB820JA065 82 1/10W 1
R6022 D0GB820JA065 82 1/10W 1
R6030 D0GBR00J0004 0
1/10W 1
R6052 D0GBR00J0004 0 1/10W 1
R6053 D0GBR00J0004 0 1/10W 1
R6054 D0GBR00J0004 0 1/10W 1
R6056 D0GBR00J0004 0 1/10W
1
R6214 D0GBR00J0004 0 1/10W 1
R6215 D0GB182JA065 1.8K 1/10W 1
R6216 D0GB122JA065 1.2K 1/10W 1
R6217 D0GB182JA065 1.8K 1/10W 1
R6245 D0GB123JA065 12K
1/10W 1
R6246 D0GB223JA065 22K 1/10W 1
R6252 D0GB223JA065 22K 1/10W 1
Safety Ref.
No.
Part No. Part Name &
Description
Qty Remarks
To Next Page
