9 Components & Controls
Figure 17: Components & controls - front view
No.
Description
No.
Description
1
Saw blade guard with suction
7
Support bolt
2
Swivel arm for saw blade guard
8
Saw blade
3
Riving knife
9
Control panel
4
Sliding shoe
10
Machine body
5
Sliding table
11
Adjustable foot
6
Telescopic swivel arm
1
6
7
8
10
11
3
2
5
4
9
