19 Options and Accessories
19.1 Sawing Units
THREE-PHASE MOTOR
WITH 7.5 KW (10 HP)
More powerful main saw motor, instead of the standard 5.5 kW motor.
SCORING UNIT 1750
0.55 KW (0.75 HP)
With manual height and lateral adjustment via externally mounted
handwheels with "APA" saw blade quick clamping system.
SCORING SYSTEM
QUICK-STEP
For manual scoring width adjustment without tools. From 2.8 to 3.8 mm
through raster adjustment by 0.05 mm / single step, incl. 1 set of saw
blades 125 x 2.8 - 3.8 x 50 mm | Z = 12+12 for system Auto-EPS & 1750.
SPARE CARBIDE
SCORING SAW BLADE
125 x 2.8 - 3.8 x 50 mm. Z = 12+12 (set = 2 pieces) for the Quick-Step
scoring system (see Art. No. 4550)
CONTROL PANEL
AT EYE LEVEL
Placed at eye level and can be swivelled.
Instead of at the bottom of the machine body.
TEMPLATE HOLDER ON
THE CONTROL PANEL
Top mounted with magnetic holder (only in combination with 4757).
19.3 Optional Fence Systems
TELE-DIGIT
CROSS-CUT FENCE
With central digital wireless indicator (accuracy 0.1 mm) for both flip
stops (up to 3000 mm), instead of standard cross-cut fence.
RIP FENCE LEFT TO
THE SAW BLADE
For cutting long, narrow parts, easily adjustable via dimension scale and
sliding flip stop with magnifying glass up to 800 mm cutting width.
Combined mitre / cross-cut fence with automatic length compensation;
for angle cuts from 45° to 135° with V2a grid curve, graduation and
intermediate degrees for 67.5°/78.75°/101.25°/112.5°; the standard
cross-cut fence can be fixed to it (unit cannot be retrofitted).
Combined mitre and cross-cut fence, length adjustable via scale, for
angle cuts from 45° to 135° with stepless angular adjustment via digital
indicator (0.01°), with automatic length compensation; the standard
cross-cut fence serves as cross-cut fence (unit cannot be retrofitted).
AUXILIARY MITRE
FENCE FOR
SUPER GEHRFIX I + II
For damage-free cutting to length of mitres or hexagons that have al-
ready been cut to size on one side. Serves as an additional fence on the
cross-cut fence. With adjustable angle for the pre-cut mitres and a fixed
offset dimension of 100 mm.
Swivelling on both sides, 45° - 60° with extendable flip stop up to 2000
mm length.
