16.1.7 Battery Change
The indicator is powered by two 1.5 V size C batteries.
Fire, explosion and burn hazard! Never recharge batteries or expose them to temperatures above
85° C. Please dispose of the used batteries properly.
Move the pull-out (3) all the way to the right against the end stop screw (10) and clamp it with lever (6).
Move slider (1) all the way to the right against end stop screw (9) and clamp with clamping screw (5).
The display now shows the stored reference dimensions for the end stop positions of both flip stops.
Slider/pull-out switchover is performed with button A) Make a note of these two values.
The slider and the pull-out must not be moved during the battery change.
Otherwise the dimensions will change and both flip stops will have to be recalibrated!
Open the battery compartment (7) shown in Figure 52 and replace the two batteries.
After the battery change, the unit automatically switches back on.
The indicator calibrates itself to the stored reference dimensions for the end stop positions.
The stored reference dimensions for the two end stop positions appear again.
If the end stop positions deviate from the values before the battery was changed, the unit must
be recalibrated (procedure see following chapter see chapter 16.1.8).
16.1.8 Set & Change Reference Dimensions
The reference dimensions are usually determined at the end stop positions (9) and (10) at the factory and are
stored in the unit. To redefine or change them, proceed as follows:
Move slider (1) all the way to the right against end stop screw (9) and clamp with clamping screw (5).
Move the pull-out (2) all the way to the right against the end stop screw (10) and clamp it with lever (6).
16.1.8.1 Set Reference Dimension for Slider
Move flip stop (3) to position X for slider (1) (see Figure 52)
Measure the distance between the saw blade and the flip stop (2) to the nearest 0.1 mm.
Enter measured dimension:
Select the “slider” with button A (see Figure 53):
The symbol (S) for the active slider (1) appears in the top line of the display.
Press buttons C + B simultaneously
oFS” for “offset” appears
Press button C once
The stored reference dimension appears and the currently changeable digit flashes.
Note: If a minus sign is flashing here, then first switch to + with button B,
so that the minus sign is hidden (+ is not shown in the display).
Select the digit to be changed with button C The 2nd digit of the display flashes.
Now set the desired numerical value by pressing button B.
Select the next digit with button C and set the value again with button B,
and so on until the measured dimension is completely entered.
Then press button C repeatedly until the display exits the calibration mode
The message “-Sto-“ appears briefly for confirmation.
