EVOHD+ Installation Guide

Programming Methods

BabyWare Uploading/Downloading Software*

We recommend programming the control panel with BabyWare. Refer to BabyWare Software on page 68 for details.

* UL Note: Not verified by UL.

Module Broadcast

Keypads and other modules can also be programmed easily by using Module Broadcast. Once a module is programmed, its sections can be sent to other similar

modules through the Digiplex bus.

Programming Through a Keypad

Use the “EVOHD+ Programming Guide” to record how the sections were programmed. To enter programming mode, use a K641+, K656+ or K641R keypad, refer to

the table below. For the TM70/TM50 press and hold the menu Icon.

For LCD Keypads: The control panel will save the data and go to the next section or press the [

ENTER] key to save the data and go to the next section. Press the

[

CLEAR] key go to the preceding step or to erase the current data entry.

Table 3:

1. Press and hold the [0] key.

2. Key in the

[INSTALLER CODE] (default = 000000).

3. Key in the 4-digit

[SECTION].

4. Key in required [DATA]. Refer to the “EVOHD+ Programming Guide” or to
