EVOHD+ Installation Guide

Input Speed

(001 to 255 X 30msec, default = 600ms)

The Input Speed defines how quickly the control panel responds to an open zone detected on any hardwired input terminal (does not apply to addressable motion

detectors and door contacts). Set the Input Speed (001 to 255 X 30ms, default = 600ms):

EOL on Hardwire Zones

SECTION [3033]: OPTION [7]

(default = disabled) If detection devices connected to hardwired input terminals use 1k

 end of line resistors, enable option [7] in section [3033]. For details on

using EOL resistors, refer to Addressable Zone Connections on page 14 and Double Zone Connections on page 16. For more information on EOL options, please refer to

the EVOHD+ programming guide.

Selectable Input Resistor

SECTION [0402]

(default = disabled) T

o select a different value for EOL resistor, please refer to the EVOHD+ Programming Guide.

Keypad Numbering

SECTIONS [2801] TO [2832]

Keypad Numbering identifies the keypad in the event buffer. The keypad is assigned to a Keypad Number from 1 to 32 through the keypad's serial number in

sections [2801] to [2832].

[0961] Input 01 [0973] Input 13 (ATZ of Input 01)

[0962] Input 02 [0974] Input 14 (ATZ of Input 02)

[0963] Input 03 [0975] Input 15 (ATZ of Input 03)

[0964] Input 04 [0976] Input 16 (ATZ of Input 04)

[0965] Input 05 [0977] Input 13 (ATZ of Input 01)

[0966] Input 06 [0978] Input 14 (ATZ of Input 02)

[0967] Input 07 [0979] Input 15 (ATZ of Input 03)

[0968] Input 08 [0980] Input 16 (ATZ of Input 04)
