EVOHD+ Installation Guide
55
Installer Function Keys
Press and hold the [0] key and key in the [INSTALLER CODE] to access the installer functions and then:
For LCD keypads: Press the key indicated in the list below that corresponds to the function you wish to activate.
Module Reset
SECTION [4001]
To reset a module connected to the Digiplex bus to its default values, key in the module's serial number into section
[4001].
Locate Module
SECTION [4002]
To locate a specific module on the Digiplex bus, key in the module's serial number into section
[4002]. The LED on the module flashes until the serial number is
entered or the module’s tamper or unlocate switch is pressed.
Module Programming
SECTION [4003]
To program a module, enter section
[4003] to enter Module Programming Mode (see section on page 19), and enter the module's serial number. To exit, press the
[CLEAR] key until Normal Mode is displayed.
Module and Label Broadcast
The EVOHD+ panel will now automatically broadcast its system labels to all modules when a new keypad is connected to the system.
S
ECTION [4004]
Module Broadcast
To copy the contents of the programming sections from one module to another, enter the serial number of the source module in section
[4004], enter the serial
numbers of all the destination modules and press
[ACC] or the center action key (Start).
Label Broadcast
Copy the User Labels, Zone Labels (sections [0301] to [0396]), the Door Labels (sections [2301] to [2332]) and the Partition Labels (sections [3100], [3200], [3300],
[3400], [3500], [3600], [3700] and [3800]) to all the modules in the system that support these labels. To transmit the labels, in section [4004], enter the control
panel’s serial number. From the Destination screen, do not enter a serial number and press
[ACC] if using an LCD keypad.
NOTE: The Module and Label Broadcast feature will only work when a module is broadcasting its data to a module or to modules of the same type and
model
number.
System Date & Time
The System Date and Time is programmed through the User Menu.
[STAY]
TEST REPORT: Sends the Test Report report code programmed in
section
[3902] to the monitoring station.
[FORCE]
CALL BABYWARE: Dials the PC telephone number programmed in
section
[3010] to communicate using BabyWare.
[ARM]
ANSWER BABYWARE: Forces the control panel to answer a call made
by the monitoring station that is using BabyWare.
[DISARM]
CANCEL COMMUNICATION: Cancels all communication with the
monitoring station or BabyWare until the next reportable event.
[MEM]
INSTALLER TEST MODE: Perform walk tests where the bell or siren
squawks once when a zone opens and twice when it closes. Press
[
MEM] again to exit. Partitions cannot be armed if the Installer Test
Mode is enabled.
[trbl]
START MODULE SCAN: Verifies the status of modules on the
Digiplex bus. The LCD Keypads display the serial number of each
module connected to the Digiplex bus.
[ACC]
START VOLTMETER READING (K641/K641R/K641LX/K641+/TM50):
Verifies if the Digiplex bus is supplying enough power at the keypad’s
location.
