38
EVOHD+ Installation Guide
Tamper Bypass Options
SECTION [3034]: OPTION [7]
(default = enabled) When enabled in section
[3034], the control panel will ignore the zone’s bypass definition and will follow the option set in section (page 37) if a
tamper or wire fault occurs on a bypassed zone. When disabled, Tamper Recognition follows the zone’s bypass definition. This means that the control panel will not
perform any action if a tamper or wire fault occurs on a bypassed zone.
Keypad Panic Options
(default = disabled) The control panel can generate an alarm (audible, fire or report only) by pressing the keypad Panic key(s). Refer to the table below for the
keypad Panic keys. In the section that corresponds to the desired partition, enable or disable options
[1] through [6]:
Report Only
The keypad emits a single confirmation beep and transmits the report code.
Audible Alarm
The control panel activates the BELL output until a user cancels the alarm or when the Bell Cut-Off Timer elapses.
Fire Alarm
Same as audible operation, except that the bell/siren output will be pulsed.
* UL Note: For UL Listed systems, all emergency non-medical and auxiliary panic alarms will be report only.
Partition 1: [3123] Partition 3: [3323] Partition 5: [3523] Partition 7: [3723]
Partition 2: [3223] Partition 4: [3423] Partition 6: [3623] Partition 8: [3823]
Option Feature Press and Hold 2 Seconds:
[1] Panic 1*
LCD keypads: Keys [1] and [3] simultaneously
[2] Panic 2*
LCD keypads: Keys [4] and [6] simultaneously
[3] Panic 3
LCD keypads: Keys [7] and [9] simultaneously
Option Alarm Type
[4] Panic 1:*
ON = Audible
OFF = Report Only
[5] Panic 2:*
ON = Audible
OFF = Report Only
[6] Panic 3:
ON = Fire
OFF = Report Only
