Enter Section [0400], then
enter the number of the zone
you want to program
Enter the zone’s 8-digit serial
and 3-digit input number
(The input number is not
needed for module with only
one input)
Enter the zone’s parameters
(01) (*2*****) default
Enter the zone’s report codes
(00) (00) (00) (00) default
Enter the zone’s label
Press [ENTER] to save and go
to the next zone
Pressing [CLEAR] twice will
exit the zone programming
menus. Press [ENTER] before
pressing clear to save your
modifications.
.
Ademco slow, Silent Knight fast, SESCOA, Ademco express formats:
Key-in desired 2-digit hex values from 00 to FF.
Ademco format:
Use section [4032] to program a set of default Ademco report codes from the Auto Report Code Programming on page 48. Then to program the
remaining report codes or to change some of the defaults, enter the individual sections and key-in the desired 2-digit hex value found in the
Appendix 2: Contact ID Report Code List on page 73.
SIA format:
Use section [4032] to program a set of SIA report codes from the Auto Report Code Programming on page 48. Codes that have not been set to
default can be set to default manually by entering FF in the appropriate section. To disable the reporting of an event, enter 00 in the appropriate
section.
Alarm Report Code Alarm Restore Report Code Tamper Report Code
Tamper Restore Report
Code
___/___ ___/___ ___/___ ___/___
In any Zone Programming option, pressing [ACC] will save the data and go to the
next zone on the same option screen. Pressing [TRBL] will save the data and go
to the previous zone on the same option screen.
ZX8 Module
Digiplex bus
Zone Definitions
Input Value Description
0 Disabled (default)
1 Entry delay 1
2 Entry delay 2
3Follow
4Instant
524 hr. buzzer
624 hr. burglary
7 24 hr. hold-up
824 hr. gas
9 24 hr. heat
A24 hr. water
B 24 hr. freeze
C Delayed 24 hr. fire
D Standard 24 hr. fire
E Stay delay 1
F Stay delay 2/Anti-mask
Partition Assignment
Input Value Description
1 Assign to partition 1
2 Assign to partition 2
3 Assign to partition 3
4 Assign to partition 4
5 Assign to partition 5
6 Assign to partition 6
7 Assign to partition 7
8 Assign to partition 8
Zone Options
Input Value(s) Description
1 Auto zone shutdown enabled
2 Bypass enabled (default: ON)
3 Stay zone
4Force zone (default: ON)
5 OFF 6 OFF (Zone Alarm) Steady alarm
5 OFF 6 ON (Zone Alarm) Pulsed alarm
5 ON 6 OFF (Zone Alarm) Silent alarm
5 ON 6 ON (Zone Alarm) Report only
7Intellizone
8 Delay before transmission
Zone Extended Options
Option Description ON
1
Zone tamper
(follow global
settings in section
[3034] option 5 & 6)
oDisabled Enabled
2 & 3
Zone tamper
supervision
-
See Zone
Tamper
-
See Zone
Tamper
4
Anti-mask trouble
(follow global
settings in section
[3029] option 5 & 6)
Disabled Enabled
5 & 6
Anti-mask
supervision
See anti-mask
Sup. Options
-
See anti-mask
Sup. Options
7 Future use ---
8 Future use ---
Zone Tamper Options
Option
Description
23
OFF OFF Disabled (default)
OFF ON Generates trouble only (when armed or disarmed)
ON OFF
When armed: alarm
When disarmed: generates trouble only
ON ON
When armed: alarm
When disarmed: generates audible alarm
Anti-mask Supervision Options
Option
Description
23
OFF OFF Disabled (default)
OFF ON Generates trouble only (when armed or disarmed)
ON OFF
When armed: alarm
When disarmed: generates trouble only
ON ON
When armed: alarm
When disarmed: generates audible alarm
Enter the zone extended
options (1**4****)
