Alarm Options
Bell/alarm Output
(default = only option [1] enabled) When an alarm condition is detected in a partition, the control panel can trigger the on-board BELL output enabling any bells or
sirens connected to it. In section
[3032] enable the option to enable the bell output in the desired partition (off = disabled):
Bell Cut-off Timer
(default = 004) After an audible alarm, the bell or siren will stop once the partition is disarmed or when the Bell Cut-Off Timer has elapsed. Enter any value between
001 and 255 minutes:
No Bell Cut-Off on Fire Alarm
SECTION [3030]: OPTION [2]
(default = disabled) The control panel can disable the Bell Cut-Off Timers when alarms are generated from zones defined as Standard or Delayed Fire Zones (see
section on page 21). The
BELL output will remain enabled until a user disarms the partition in alarm.
Recycle Alarm Rate
(default = 000) The control panel re-verifies the zone status during an alarm at a programmed rate once the Bell Cut-Off Timer and the Recycle Delay elapse. If open
zones remain, the control panel will regenerate the alarm. Enter the number of times from 001 to 255 (000 = no limit) in one armed period that the control panel will
re-verify the zone status:
Recycle Delay
(default = 000) The Recycle Delay is the amount of time the control panel will wait after the Bell Cut-off occurs before re-verifying the zone status. Program the
Recycle Delay from 001 to 255 minutes (000 = disabled):
Wireless Transmitter Supervision Options
SECTION [3034]: OPTIONS [1] AND [2]
When the control panel detects a Supervision Loss, the control panel can generate an alarm and/or trouble, unless the Wireless Transmitter Supervision Option is
disabled.
Supervision Bypass Options
SECTION [3034]: OPTION [3]
(default = disabled) When enabled in section
[3034], the Wireless Transmitter Supervision Options will follow the zone's bypass definition. The control panel will not
perform any action if a supervision loss occurs on a bypassed zone. When disabled, it will ignore the bypass definition and will follow the option set in section .
Partition 1: Option [1] Partition 5: Option [5]
Partition 2: Option [2] Partition 6: Option [6]
Partition 3: Option [3] Partition 7: Option [7]
Partition 4: Option [4] Partition 8: Option [8]
Partition 1: [3113] Partition 3: [3313] Partition 5: [3513] Partition 7: [3713]
Partition 2: [3213] Partition 4: [3413] Partition 6: [3613] Partition 8: [3813]
Partition 1: [3117] Partition 3: [3317] Partition 5: [3517] Partition 7: [3717]
Partition 2: [3217] Partition 4: [3417] Partition 6: [3617] Partition 8: [3817]
Partition 1: [3116] Partition 3: [3316] Partition 5: [3516] Partition 7: [3716]
Partition 2: [3216] Partition 4: [3416] Partition 6: [3616] Partition 8: [3816]
[1] [2] Description
OFF OFF
Disabled (default):
Displays zone open on the keypads, therefore will generate an alarm when the system is armed.
Not permitted on UL systems.
OFF ON
Generates Trouble Only (when armed or disarmed):
The control panel displays Zone Fault in the Trouble Display and transmits the defined report
code (see
section on page 40).
ON OFF
When disarmed: Generates Trouble Only
The control panel displays Zone Fault in the Trouble Display and transmits the defined report
code (see
section on page 40).
When armed: Follows Zone Alarm Type
The control panel follows the zone’s alarm type (see
section on page 24).
ON ON
When disarmed: Generates Audible Alarm
The control panel displays Zone Fault in the Trouble Display, transmits the defined report code
(see
section on page 40), and generates an audible alarm.
When armed: Follows Zone Alarm Type
The control panel follows the zone’s alarm type (see
section on page 24).
