Object list
COMPAX CANopen
OUTPUT_MASK
54
6.15.4 OUTPUT_MASK
Mask outputs.
Each output which is to be influenced via the object OUTPUT_WORD must be explicitly released (masked) for this purpose.
The output thereby loses any status information which was assigned to it.
OUTPUT-MASK directly reads/describes the parameters P223 (LSB) and P224 (MSB).
Object Description
Index
0x2041
Symbol
OUTPUT_MASK
Length
2
Min
0x0000
Object code
Variable
Max
0xFFFF
Data type
Unsigned16
Access rights
read/write
PDO mapping
no
Data Description
Bit Assignment Parameter
15 ... 8 Mask output 16...9 P224/Bit 7 ... 0
7...0 Mask output 8...1 P223/Bit 7 ... 0
