PAX S90 User Manual

Chapter 6
How to Set the POS terminal
NOTE: This document is CONFIDENTIAL and must be used exclusively for the operation of PAX programs. It may not be
duplicated, published, or disclosed without PAX prior written permission. 167
Sample of Print EDC Setup Report
Note
Please review the following samples of receipts.
02/03/2011 11:11:19
================================
EDC Setup
================================
Terminal Number: 1000731686
Serial Number: 000000731686
--------------------------------
Host Name 14.6D CREDIT
TERMINAL BASE
Merchant_Number: 123456
Terminal_ID: 123456
Auth. Phones:
Phone1: 18005551234
Baud Rate: 1200, 7E
Phone2: 18005552345
Baud Rate: 1200, 7E
Phone 3: 18005553456
Baud Rate: 1200, 7E
# of tries: 1
Batch Phones:
Phone1: 18005551234
Baud Rate: 1200, 7E
Phone2: 18005552345
Baud Rate: 1200, 7E
Phone 3: 18005553456
Baud Rate: 1200, 7E
# of tries: 1
--------------------------------
Host Name 14.6D DEBIT
HOST BASE AUTOBATCH
Params Same as CREDIT
Auth. Phones:
Phone1: 18005554567
Baud Rate: 1200, 7E
Phone2: 18005555678
Baud Rate: 1200, 7E
Phone 3: 18005556789
Baud Rate: 1200, 7E
# of tries 1
DBT BATCH THROUGH CREDIT
--------------------------------
Host Name 21.4B CHECK
HOST BASE AUTOBATCH
Client_Number 123456
Auth. Phones:
Phone1: 18005554321
Baud Rate: 1200, 7E
Phone2: 18005555432
Baud Rate: 1200, 7E
Phone 3: 18005556543
Baud Rate: 1200, 7E
# of tries: 1
--------------------------------
Host Name 4.41A EBT
HOST BASE MANUAL
Merchant_Number: 123456
Terminal_ID: 123456
BIN_Number: 123456
Auth. Phones:
Phone1: 18005551111
Baud Rate: 1200, 7E
Phone2: 18005552222
Baud Rate: 1200, 7E
Phone 3: 18005553333
Baud Rate: 1200, 7E
# of tries: 1
Batch Phones:
Phone1: 18005554444
Baud Rate: 1200, 7E
Phone2: 18005555555
Baud Rate: 1200, 7E
Phone 3: 18005556666
Baud Rate: 1200, 7E
# of tries: 1
================================
AutoDial Settings:
CREDIT ON
AutoDial Begins: 03:00
AutoDial Ends: 04:00
Interval: 5
Retries: 13
DEBIT: OFF
CHECK: OFF
EBT ON
AutoDial Begins: 22:00
AutoDial Ends: 23:00
Interval: 5
Retries: 13
Notice the AutoBatch Hosts do
not have AutoDial settings.
