32
Parameter “Alloy Positive”.
DO NOT MODIFY.
Tolerance on parameter “Alloy Positive”.
DO NOT MODIFY.
DO NOT MODIFY.
Y Standard. Parameters “DLXX” are enabled.
N Parameters “DLXX” are NOT enabled.
Parameter “DL70”
The measure is taken by “Enable DLXX = Y”
DO NOT MODIFY.
Tolerance on parameter “DL70”
DO NOT MODIFY.
Parameter “DL10”.
The measure is taken by “Enable DLXX = Y”.
Do NOT MODIFY.
Tolerance on parameter “DL10”.
DO NOT MODIFY.
Parameter “F”.
DO NOT MODIFY.
Tolerance on parameter “F”.
DO NOT MODIFY.
Advanced parameter for coin discrimination.
DO NOT MODIFY
Delta on coin parameters
"DELTAs" are tolerance values on coin parameters. When a coin is being programmed, the Delta is automatically
calculated for each parameter.
Delta values can be modified to adjust coin acceptance.
E.g.: when a parameter is 150 with a Delta of 10, that coin is recognized with a value between 140 and 160.
In the case of a poor acceptance, try programming the coins rejected in a free channel and compare their nominal
values with default ones.
When a new channel is added, tolerance on coin parameters can be increased.
Delta values cannot be modified in protected channels !
Coin No. 1
Enable DLXX:
Coin No. 1
D-DL70: ---
Coin No. 1
D-AlloyPhase+: --
Coin No. 1
D-Parameter F: --
Coin No. 1
AlloyPhase+: ----
Coin No. 1
DL70: ---
Coin No. 1
Parameter F ---
Coin No. 1
D-DL10: ---
Coin No. 1
DL10: ---
Coin No. 1
Discrimination 0
