Paytec Eagle - Page 87

87
Table 7
Table 6
LED signals on key reader
Key reader status/errors are indicated by LED signals on Paytec
®
key reader faceplate (see table 6).
When a problem is not solved with the solution suggested, contact Paytec.
LED Solution
OFF Reader OFF
GREEN FLASHING Reader ON, ready for use
GREEN ON Key inserted and accepted (it can be pulled out now)
RED ON Writing… (don’t pull out the key)
YELLOW ON
▪ The key has not been recognized
▪ Sensor darkened when giving power
YELLOW FLASHING Extended Audit full
Messages on system status
The messages in table 7 are displayed on the changegiver LCD to indicate a temporary system status.
Message Description
PC
PC RS232 mode
P6000
Connecting with P6000…
InH
System inhibited, or inhibited by VM
Audit
Transmitting Audit …
Conf
Transmitting/receiving configuration…
CLEAR
Resetting Audit …
FREE
TestKey inserted
OFF
Timed OFF
Euro
Starting message when EAGLE is configured in Euro
MM-NN
Message displayed while programming coins:
MM = no. coins inserted so far
NN = total no. coins required
FILL
Filling tubes ... (from setup menu)
CAL
Calibrating coin validator ...(wait, please)
-
CAL
-
Calibrating coin validator after firmware update...(wait, please).
CFGCh
Coin parameters have been modified
SETUP
Access to SETUP menu from tube keypad
TubeL
Setup menu: read level in tube
Tube
Setup menu: adjust max. level in tubes
Price
Setup menu: enter prices
Dest
Setup menu: coin destination
ErClr
Setup menu: reset errors
Fill
Setup menu: filling tubes
[] []
Calibrating…
dSPUP
Updating DSC ... (wait, please)
Ln
Updating counter DSC (wait, please)
noLink
Serial link with VM interrupted (e.g. cable accidentally unplugged)
nodSP
Communication error with DSC (switch OFF and ON again)
