MY19-P073_1.0_09.11.2018
101
Maintenance
8.3.4 Adjusting the gear shift
If you cannot select the gears effortlessly, you will
need to adjust the setting for the shift cable tension.
Carefully pull the adjusting sleeve away from the
shifter housing, turning it as you do so.
Check the gear shift function after each adjustment.
8.3.4.1 Cable-operated gear shift, single-cable
Alternative
For a smooth gear shift, adjust the adjusting
sleeves on the shifter housing.
Figure 52: Adjusting sleeve (1) for the single-cable cable-operated gear shift
with shifter housing (2), example
If you are unable to adjust the gear shift in this way, the
specialist dealer will need to check the gear shift
assembly.
EN_MY19-P073_1.0_31.08.2018_Pegasus Fahrrad MY19_Inhalt.book Page 101 Friday, November 9, 2018 4:59 PM
