MY19-P073_1.0_09.11.2018
47
Transportation, storage and assembly
 Insert the axle into the hub on the drive side.
Clamping version II.
Figure 21: Pushing the axle into the hub
 Tighten the axle with the red handle.
Figure 22: Tightening the axle
